Specifications
Place of Origin :
China
Brand Name :
HUATEC
Certification :
CE
Model Number :
TG8829
MOQ :
1 set
Packaging Details :
Carton
Delivery Time :
3-7 working days
Payment Terms :
TT, L/C, Western Union
Measuring range :
0-1250um/0-50mil
Resolution :
0.1/1um
Min. measuring area :
5mm
Min. sample thickness :
0.3mm
Power supply :
4x1.5V AAA(UM-4)battery
Dimension :
124x62x30mm
Description
5mm Inspection Size Coating Thickness Gauge TG8829 with the Measuring Range 0 - 1250um
Description:
Operating principle: magnetic induction/eddy current (F/NF)
With separate probe(s)
Measuring range: 0-1250um/0-50mil
Resolution: 0.1/1um
Accuracy: ±1-3%n or ±2.5um
Min. measuring area: 5mm
Min. sample thickness: 0.3mm
Battery indicator: low battery indicator
Metric/ imperial: convertible
Power supply: 4x1.5V AAA(UM-4)battery
Auto power off
Operating conditions: 0-+45℃(32℉-104℉), ≤90%RH
Dimensions: 124x62x30mm
weight: 115g
Standard Delivery of Film Thickness Gauge TG8829FN
Main unit 1
F type probe 1
N type probe 1
F calibration base set 1
N calibration base set 1
Calibration foil set 1set (4 foils)
Carrying case 1
Instruction manual 1
Optional Accessories of Paint Thickness Gauge TG8829FN
Cable and software for RS-232C
Customized testing range
