Medical Automatic Film Processor , Tablet X Ray Dental Film Processor

Specifications

Brand Name :

HUATEC

Model Number :

HDL-P14/P17

Certification :

ISO CE

Place of Origin :

CHINA

MOQ :

Payment Terms :

T/T, Western Union

Supply Ability :

500

Packaging Details :

in carton

Film specification :

Minimum 10*10cm maximum 35*∞cm

Flushing time :

105、135、165sec

Developing time :

28、36、44sec

Flushing volume :

80 pieces / hours（14"*17"）120 pieces / hours（11"*14"）

Drug tank capacity :

Developing, fixing, and washing each 5.2L

Description

Medical Automatic Film Processor , Tablet X Ray Dental Film Processor

HUATEC HDL-P14/P17 Medical tablet X Ray film processor

Medical Automatic Film Processor , Tablet X Ray Dental Film Processor

Standard equipment

1. development synchronous heating system

2. development of independent circulation system

3. development synchronous supplementary system

4. water controlled water saving system of solenoid valve

5. professional conical air duct drying system

6. mechanical sensing feeding system

7. DKM electronic speed control energy saving system

Model	HDL-P14	HDL-P14A	HDL-P17	HDL-P17A
Film specification	Minimum 1010cm maximum 35∞cm		Minimum 1010cm maximum 45∞cm
Flushing time	105,135,165sec	90-360sec	105,135,165sec	90-360sec
Developing time	28,36,44sec	20-60sec	28,36,44sec	20-60sec
Flushing volume	80 pieces / hours(14"17")120 pieces / hours(11"14")	110 pieces / hours(14"17")160 pieces / hours(11"14")	100pieces / hours(14"17")155 pieces / hours(11"14")	140 pieces / hours(14"17")210 pieces / hours(11"14")
Drug tank capacity	Developing, fixing, and washing each 5.2L	Developing, fixing, and washing each 5.2L	Developing, fixing, and washing each 8L	Developing, fixing, and washing each 8L
Developer temperature	28℃-37 ℃adjustable (interval 1℃)	20℃-40 ℃adjustable (interval 0.1℃)	28℃-37 ℃adjustable (interval 1℃)	20℃-40 ℃adjustable (interval 0.1℃)
Drying temperature	40℃-65 ℃(automatic regulation)	40℃-65 ℃(automatic regulation)	40℃-65 ℃(automatic regulation)	40℃-65 ℃(automatic regulation)
Film induction	Imported microswitch	Imported microswitch	Imported microswitch	Imported microswitch
Volume ㎝³	795942	795942	796942	796942
weight	Gross weight 50kg (net weight 45kg)		Gross weight 60kg (net weight 55kg)
Anti crystallization and anti oxidation	45 minutes / times
Flushing process	Development→Fixed shadow→washing→Dry
Supplement	According to the area of film flushing, automatic water replenishment is provided, and manual replenishment is also provided. The amount of water replenishment is 20-200ml/0.3㎡
Water washing control	When the film is flush, it will automatically water for 2-8L/ minutes, and automatically shut down when standby.
Power consumption	220V 50/60Hz 8.8A (flushing 2KW, standby 120W)
