Surface Roughness Gage Surface Roughness Instrument Surface Roughness Measuring Instrument
Surface Roughness Gage Surface Roughness Instrument Surface Roughness Measuring Instrument
Surface Roughness Gage Surface Roughness Instrument Surface Roughness Measuring Instrument
Surface Roughness Gage Surface Roughness Instrument Surface Roughness Measuring Instrument
Specifications
Brand Name :
HUATEC
Model Number :
SRT-6210CT
Certification :
ISO CE
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T, Western Union
Supply Ability :
500
Standards :
GB/T6062,ISO4287,DIN4768,JIS B,ANSI46.1
Parameters :
Ra,Rq,Rz,Rt
Measuring Range :
Ra,Rq:0.005~20.00µm Rz,Rt:0.020~200.0µm
Accuracy :
≤±10%
Resolution :
0.001/0.01/0.1
Radius of Probe Pin :
10µm
Operating Conditions :
Temp:0~50ºC Humidity:<80%RH
Description

Surface Roughness Gage Surface Roughness Instrument Surface Roughness Measuring Instrument

Concrete Surface Texture Tester SRT-6210CT

Surface Roughness Gage Surface Roughness Instrument Surface Roughness Measuring Instrument

Application

Widely used in construction site to measure surface roughness of concrete.

Feature

* Be compatible with four standards of ISO, DIN, ANSI and JIS.
* Multiple parameter measurement: Ra, Rz, Rq, Rt.
* Highly sophisticated inductance sensor.
* Four wave filtering methods : RC, PC-RC, GAUSS and D-P.
* Built-in lithium ion rechargeable battery and control circuit with high capacity.
* Small in size, light in weight and easy to use.
* Manual or automatic shut down.
* Can memorize 7 groups of measurement results and measuring conditions for later use or download to PC.
* Metric /Imperial Conversion.
* Use USB/RS-232 data output to connect with PC.
* Provide Bluetooth data output choice.

Principle

When measuring the roughness of a surface, the sensor is placed on the surface and then uniformly slides along the surface by driving the mechanism inside the tester. The sensor gets the surface roughness by the sharp built-in probe. This roughness causes displacement of the probe which results in change of inductive amount of induction coils so as to generate analogue signal, which is in proportion to the surface roughness at output end of phase-sensitive rectifier. The exclusive DSP processes and calculates and then outputs the measurement results on LCD.

Specification

Standards GB/T6062,ISO4287,DIN4768,JIS B,ANSI46.1
Parameters Ra,Rq,Rz,Rt
Measuring Range Ra,Rq:0.005~20.00µm Rz,Rt:0.020~200.0µm
Accuracy ≤±10%
Fluctuation of Display Value ≤6%
Resolution 0.001/0.01/0.1
Sensor Radius of Probe Pin 10µm
Material of Probe Pin Diamond
Measurement Force of Probe 16mN(1.6gf)
Probe Angle 90º
Vertical Radius of Guiding Head 48 mm
Maximum Driving Stroke 17.5mm/0.7inch
Cutoff length(l) 0.25mm,0.8mm,2.5mm
Driving Speed Sampling When Length=0.25mm,Vt=0.135 mm/s
When Length=0.8mm,Vt=0.5mm/s
When Length=2.5mm,Vt=1mm/s
Returning Vt=1mm/s
Profile Digital Filter RC,PC-RC,GAUSS,D-P
Evaluation Length 1~5L Optional
Data Memorize 7 Groups
Operating Conditions Temp:0~50ºC Humidity:<80%RH
Power Supply Bulit-in Rechargeable Li-ion Battery
Dimensioms 140x52x48mm
Weight 420g
Standard Accessories Main Unit
Standard Sample Plate SSP-100
Standard Sensor SSP-100
Small Screwdriver
Power Adapter
Carrying Case ( B09 )
Operation Manual
Optinal Accessories RS-232C Cable with Software
Bluetooth Adapter with Software
Extension Rod SER-150
Groove Stylus SRP-110
Curvature Probe SRP-120
Measurement Stand SRS-1

Probe
