HG6378-3 3-Channel 3D XYZ Piezoelectric Accelerometer Wide Frequency Range Vibration Tester
HG6378-3 3-Channel 3D XYZ Piezoelectric Accelerometer Wide Frequency Range Vibration Tester
HG6378-3 3-Channel 3D XYZ Piezoelectric Accelerometer Wide Frequency Range Vibration Tester
HG6378-3 3-Channel 3D XYZ Piezoelectric Accelerometer Wide Frequency Range Vibration Tester
Specifications
Brand Name :
HUATEC
Model Number :
HG6378-3
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Price :
USD667/set - USD754/set
Payment Terms :
T/T,Paypal
Supply Ability :
10sets/Month
Delivery Time :
7-10 working days after receipt of your payment
Packaging Details :
Carton packing box
Description

HG6378-3 3-Channel 3D XYZ Piezoelectric Accelerometer Wide Frequency Range Vibration Tester

Application

Used for measuring periodic motion, to check the imbalance and deflecting of moving machinery.

Features

* 3 same parameters in one display for 3 dimensional measurement or 1 dimensional measurement specified, showing 3 different parameters of velocity, acceleration and displacement in 1 display.
* In accordance with ISO 2954, used for periodic measurements, to detect out-of-balance, misalignment and other mechanical faults in rotating machines.
* Specially designed for easy on site vibration measurement of all rotating machinery for quality control,commissioning, and predictive maintenance purposes.
* Individual high quality accelerometer for accurate and repeatable measurements.
* Wide frequency range (10Hz~10kHz) in acceleration mode.
* Optional headphones for use as electronic stethoscope.
* Bearing condition monitoring function.
* Use USB/RS-232 data output to connect with PC.
* Provide Blue tooth data output choice.

Vibration Standard

ISO/IS2373 Motor Quality Standard According As Vibration Velocity
Quality Rank Rev(rpm) H:high of shaft(mm)
Maximum vibration velocity rms(mm/s)
80<H<132 132<H<225 225<H<400
Normal 600~3600 1.8 2.8 4.5
Good(R) 600~1800 0.71 1.12 1.8
1800~3600 1.12 1.8 2.8
Excellent(S) 600~1800 0.45 0.71 1.12
1800~3600 0.71 1.12 1.8

Specification

Sensor Piezoelectric Transducer
Measuring Range Acceleration 0.1~400m/s² 0.3~1312ft/s² 0.0~40g Equivalent Peak
Velocity 0.01~400mm/s 0.004~16.0inch/sTrue RMS
Displacement 0.001~4.0 mm 0.04~160.0 mil Equivalent Peak-peak
Frequency Range Acceleration 10Hz~10kHz
Velocity 10Hz~1kHz
Displacement 10Hz~1kHz
Accuracy 5% of Reading+2 digits
Operating Conditions Temperature 0~50ºC
Humidity <90%RH
Power Supply 2x1.5V AA(UM-3)Battery
Dimensions 137x76x32mm
Weight 425g(Not Including Batteries)
Standard Accessories Main Unit
Piezoelectric Transducer
Powerful Rare Earth Magnet
Probe(Cone)&Probe(Spherical)
Carrying Case(B04)
Manual Book
Optional Accessories Headset
RS-232C Data Cable with Software
Bluetooth Data Adapter with Software
