RNAO 5x10x8 Steel Needle Roller Bearing Open Seals Type For Engine Parts
RNAO 5x10x8 Steel Needle Roller Bearing Open Seals Type For Engine Parts
RNAO 5x10x8 Steel Needle Roller Bearing Open Seals Type For Engine Parts
RNAO 5x10x8 Steel Needle Roller Bearing Open Seals Type For Engine Parts
RNAO 5x10x8 Steel Needle Roller Bearing Open Seals Type For Engine Parts
RNAO 5x10x8 Steel Needle Roller Bearing Open Seals Type For Engine Parts
Specifications
Brand Name :
NEKIB OR FUMSB
Model Number :
RNAO 5*10*8
Certification :
ISO9001,IATF16949
Place of Origin :
CHANGZHOU,CHINA
MOQ :
100
Price :
0.1-100$ one piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
300kpcs,30days
Delivery Time :
5-8 work days
Packaging Details :
Roll or single box
Precision Ratingow :
P0,P3, P4,P5,P6
Seals Type :
Open
Cage :
Steel,brass,Nylon
Application :
machine tool
Specification :
Customed
HS Code :
8482102000
Description

High precision/Steel needle roller bearing without shoulder on inner ring/RNAO series for engine parts

Description:

Sealed needle roller bearings with or without inner ring
Single or double-sided sealed needle roller bearings can effectively prevent the intrusion of dirt, and the bearing has been filled with an appropriate amount of lithium-based grease. The inner ring of this type of bearing is wider than the outer ring, which allows the bearing to ensure a good seal when the shaft has a small displacement relative to the bearing box to avoid bearing contamination. The inner ring of the bearing also has lubrication holes, which can be relubricated by the outer ring or the inner ring according to the needs of the configuration.

Features:

1) Precision: ABEC-1(P0), ABEC-3(P6), ABEC-5(P5), ABEC-7(P4)

2) Noise level: Z1, Z2, Z3, Z4

3) Vibration Level: V1, V2, V3, V4

4) Clearance: C2, C3, C4

6) Grease: As your requirement, such as SRL, PS2, Alvania R12 and so on.

Drawings:

RNAO 5x10x8 Steel Needle Roller Bearing Open Seals Type For Engine PartsRNAO 5x10x8 Steel Needle Roller Bearing Open Seals Type For Engine Parts

No inner ring solid ferrule needle bearing RNA NK series

Catalogue:

shaft Model Boundary dimensions Basic load rating Limiting Speed
FW D C rS Dynamic Static Oil
C Co
mm mm Min. N rpm
48 RNA4908 48 62 22 0.6 43000 67000 9000
RNA6908 48 62 40 0.6 66000 116000 9000
50 NK 50/25 50 62 25 0.6 38000 74000 9000
NK 50/35 50 62 35 0.6 55000 106000 9000
NKS50 50 65 22 1 42500 67000 9000
52 RNA4909 52 68 22 0.6 45000 73000 8500
RNA6909 52 68 40 0.6 69000 127000 8500
55 NK 55/25 55 68 25 0.6 40000 82000 8500
NK 55/35 55 68 35 0.6 53000 118000 8500
NKS55 55 72 22 1 45000 74000 8000
58 RNA4910 58 72 22 0.6 47000 80000 8000
RNA6910 58 72 40 0.6 73000 139000 8000
60 NK 60/25 60 72 25 0.6 42000 90000 7500
NK 60/35 60 72 35 0.6 56000 130000 7500
NKS60 60 80 28 1.1 63000 98000 7500
63 RNA4911 63 80 25 1 58000 100000 7000
RNA6911 63 80 45 1 90000 176000 7000
65 NK 65/25 65 78 25 0.6 44000 98000 7000
NK 65/35 65 78 35 0.6 59000 142000 7000
NKS65 65 85 28 1.1 67000 108000 7000
68 NK 68/25 68 82 25 0.6 43500 89000 7000
ML 68/35 68 82 35 0.6 62000 139000 7000
RNA4912 68 85 25 1 60000 108000 6500
RNA6912 68 85 45 1 94000 191000 6500
70 NK 70/25 70 85 25 0.6 44500 92000 6500
NK 70/35 70 85 35 0.6 63000 144000 6500
NKS70 70 90 28 1.1 68000 113000 6500
72 RNA4913 72 90 25 1 61000 112000 6500
RNA6913 72 90 45 1 95000 198000 6500
73 NK 73/25 73 90 25 1 53000 100000 6500
NK 73/35 73 90 35 1 75000 156000 6500
75 NK 75/25 75 92 25 1 54000 104000 6000
NK 75/35 75 92 35 1 77000 162000 6000
NKS75 75 95 28 1.1 71000 123000 6000
80 NK 80/25 80 95 25 1 56000 119000 6000
NK 80/35 80 95 35 1 78000 184000 6000
NKS80 80 100 28 1.1 75000 133000 5500
RNA4914 80 100 30 1 84000 156000 5500
RNA6914 80 100 54 1 128000 265000 5500
85 NK 85/25 85 105 25 1 69000 123000 5500
NK 85/35 85 105 35 1 98000 193000 5500

and so on.
