Pm44140 Needle Bearing Roller And Pin Bearing Steel Material Multi Column 82077090
Pm44140 Needle Bearing Roller And Pin Bearing Steel Material Multi Column 82077090
Pm44140 Needle Bearing Roller And Pin Bearing Steel Material Multi Column 82077090
Pm44140 Needle Bearing Roller And Pin Bearing Steel Material Multi Column 82077090
Specifications
Brand Name :
NEKIB OR FUMSB
Model Number :
Pm44140
Certification :
ISO9001,IATF16949
Place of Origin :
CHANGZHOU,CHINA
MOQ :
100
Price :
0.1-100$ one piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
300kpcs,30days
Delivery Time :
5-8 work days
Packaging Details :
Roll or single box
Material :
Bearing Steel
Load Direction :
Radial Bearing
HS Code :
82077090
The Number of Rows :
Multi-column
Size :
According to Drawing
Quality :
Standard Pin
Description

Pm44140 roller and pin for High Pressure Grinding Roller/Iron Ore/Cement Cr

Description:

It is suitable for all kinds of high precision needle roller bearings and needle roller bearings.

Rolling Element

Rolling Element Specification (mm) Boundary Dimensions (mm)

Weight

Per 1000pcs (Kg)
Dw Lw
Needle Roller
1.35X3.6 1.35 3.6 0.039
1.49X6.8 1.49 6.8 0.092
1.5X5.8 1.5 5.8 0.08
1.5X6.8 1.5 6.8 0.094
1.5X7.8 1.5 7.8 0.108
1.5X9.8 1.5 9.8 0.136
1.5X11.8 1.5 11.8 0.164
1.5X13.8 1.5 13.8 0.191
1.5X19.8 1.5 19.8 0.267
1.5X21.8 1.5 21.8 0.295
1.505X4 1.505 4 0.053
1.532X3.8 1.532 3.8 0.054
1.5875X9.65 1.5875 9.65 0.13
1.6X9.8 1.6 9.8 0.149
1.6X11.8 1.6 11.8 0.18
1.6X17.8 1.6 17.8 0.273
1.811X13.46 1.811 13.46 0.253
1.8313X12.14 1.8313 12.14 0.246
1.984X15.3 1.984 15.3 0.366
1.984X20.15 1.984 20.15 0.476
1.994X16.25 1.994 16.25 0.392
2X4 2 4 0.095
2X6.8 2 6.8 0.16
2X7.8 2 7.8 0.19
2X8.8 2 8.8 0.206
2X9.8 2 9.8 0.24
2X10.8 2 10.8 0.259
2X11 2 11 0.268
2X11.8 2 11.8 0.29
2X12.3 2 12.3 0.298
2X12.8 2 12.8 0.28
2X13.6 2 13.6 0.33
2X13.8 2 13.8 0.34
2X15.8 2 15.8 0.39
2X17.8 2 17.8 0.44
2X19.8 2 19.8 0.49
2X21.8 2 21.8 0.54
2.1X6 2.1 6 0.16
2.249X6.3 2.249 6.3 0.187
2.413X16.63 2.413 16.63 0.587
2.5X7.8 2.5 7.8 0.3
2.5X9.8 2.5 9.8 0.38
2.5X11.8 2.5 11.8 0.45
2.5X13.8 2.5 13.8 0.53
2.5X14.8 2.5 14.8 0.563
2.5X15.8 2.5 15.8 0.61
2.5X16.7 2.5 16.7 0.639
2.5X17.3 2.5 17.3 0.658
2.5X17.8 2.5 17.8 0.69
2.5X19.2 2.5 19.2 0.735
2.5X19.8 2.5 19.8 0.76
2.5X21.8 2.5 21.8 0.84
2.5X22.3 2.5 22.3 0.85
2.5X23.8 2.5 23.8 0.92
2.5X26.8 2.5 26.8 1.02
2.5X28.8 2.5 28.8 1.089
2.5X29.8 2.5 29.8 1.1
2.51X10 2.51 10 0.37
2.51X11 2.51 11 0.41
2.52X10 2.52 10 0.371
2.52X11 2.52 11 0.431
2.53X10 2.53 10 0.375
2.54X10 2.54 10 0.376
2.54X11 2.54 11 0.42
2.55X10 2.55 10 0.38
2.55X11 2.55 11 0.428
2.55X14.6 2.55 14.6 0.583
2.56X10 2.56 10 0.383
2.565X10 2.565 10 0.403
2.57X10 2.57 10 0.396
2.58X10 2.58 10 0.41
2.58X11 2.58 11 0.438
2.60X10 2.6 10 0.398
2.6X11 2.6 11 0.458
2.62X10 2.62 10 0.416
2.63X10 2.63 10 0.407
2.65X10 2.65 10 0.412
2.67X10 2.67 10 0.432
2.7X10 2.7 10 0.436
3X5.75 3 5.75 0.31
3X6 3 6 0.32
3X7.8 3 7.8 0.393
3X8 3 8 0.427
3X9.5 3 9.5 0.523
3X9.8 3 9.8 0.54
3X10 3 10 0.538
3X11.8 3 11.8 0.65
3X12.8 3 12.8 0.6931
3X13.8 3 13.8 0.76
3X14 3 14 0.74
3X14.8 3 14.8 0.82
3X15.8 3 15.8 0.87
3X17.8 3 17.8 0.99
3X19.8 3 19.8 1.1
3X21.8 3 21.8 1.21
3X23.8 3 23.8 1.32
3X24.8 3 24.8 1.361
3X25.8 3 25.8 1.43
3X27.8 3 27.8 1.54
3X29.8 3 29.8 1.61
3X31.8 3 31.8 1.723
3X39.8 3 39.8 2.164
3.01X10 3.01 10 0.532
3.01X11.8 3.01 11.8 0.623
3.02X10 3.02 10 0.52
3.02X11.8 3.02 11.8 0.627
3.03X10 3.03 10 0.539
3.03X11.8 3.03 11.8 0.631
3.05X8 3.05 8 0.441
3.05X11.8 3.05 11.8 0.657
3.1X11.8 3.1 11.8 0.62
3.16X6.7 3.16 6.7 0.403
3.175X23.11 3.175 23.11 1.413
3.2X5.9 3.2 5.9 0.376
3.2X6 3.2 6 0.376
3.2X6.4 3.2 6.4 0.389
3.5X11.8 3.5 11.8 0.91
3.5X13.8 3.5 13.8 1.05
3.5X15.8 3.5 15.8 1.19
3.5X17.8 3.5 17.8 1.35
3.5X19.8 3.5 19.8 1.51
3.5X21.8 3.5 21.8 1.67
3.5X23.8 3.5 23.8 1.85
3.5X25.8 3.5 25.8 1.96
3.5X27.8 3.5 27.8 2.1
3.5X29.8 3.5 29.8 2.25
3.5X31.8 3.5 31.8 2.373
3.5X34.8 3.5 34.8 2.65
3.55X6.5 3.55 6.5 0.501
3.55X6.6 3.55 6.6 0.509
3.55X12.8 3.55 12.8 0.968
3.60X12.8 3.6 12.8 1
3.65X12.8 3.65 12.8 1.021
3.967X19.05 3.967 19.05 1.802
4X10 4 10 0.97
4X12 4 12 1.164
4X13.8 4 13.8 1.28
4X15.8 4 15.8 1.55
4X17.8 4 17.8 1.75
4X19.8 4 19.8 1.95
4X21.8 4 21.8 2.14
4X23.8 4 23.8 2.33
4X25.8 4 25.8 2.53
4X27.8 4 27.8 2.62
4X29.8 4 29.8 2.95
4X33.8 4 33.8 3.25
4X34.8 4 34.8 3.4
4X37.8 4 37.8 3.64
4X38.8 4 38.8 3.74
4X39.8 4 39.8 3.9
4.018X18.8 4.018 18.8 1.842
4.02X15.8 4.02 15.8 1.478
4.05X15.8 4.05 15.8 1.48
4.10X15.8 4.1 15.8 1.482
4.5X13.8 4.5 13.8 1.683
4.505X8 4.505 8 0.994
4.902X25.019 4.902 25.019 3.68
5X14.8 5 14.8 2.115
5X17.8 5 17.8 2.587
5X18.8 5 18.8 2.798
5X19.8 5 19.8 3.03
5X20.5 5 20.5 3.1
5X21.8 5 21.8 3.36
5X23.8 5 23.8 3.58
5X24.8 5 24.8 3.82
5X25.8 5 25.8 3.98
5X27.8 5 27.8 4.18
5X29.8 5 29.8 4.6
5X34.8 5 34.8 5.4
5X38 5 38 5.857
5X39.8 5 39.8 6.15
5X44.8 5 44.8 6.74
5X49.8 5 49.8 7.5
5X59.8 5 59.8 9.131
5.296X9.652 5.296 9.652 1.633
5.5X17 5.5 17 3.078
5.66X19.8 5.66 19.8 3.681
5.66X29.8 5.66 29.8 5.7
5.951X24.13 5.951 24.13 5.195
6X13 6 13 2.6
6X18 6 18 3.9
6X19.8 6 19.8 4.12
6.0X21.8 6 21.8 4.57
6X23.8 6 23.8 5.243
6X24.8 6 24.8 5.381
6X29.8 6 29.8 6.36
6X34.8 6 34.8 7.594
6X35.8 6 35.8 7.816
6X39.8 6 39.8 8.703
6X43.8 6 43.8 9.591
6X44.8 6 44.8 9.813
6X49.8 6 49.8 10.923
6X59.8 6 59.8 13.03
6.35X20.624 6.35 20.624 5.06
6.35X30.8 6.35 30.8 7.56
7X14 7 14 4.2
7X21 7 21 6.317
7X27 7 27 8.096
7X38 7 38 11.5
7X41 7 41 12.128
7.071X29.8 7.071 29.8 9.197
7.62X25.4 7.62 25.4 9.015
7.85X15.87 7.85 15.87 5.958
7.94X11.1 7.94 11.1 4.168
7.94X18.03 7.94 18.03 6.879
7.94X19.05 7.94 19.05 7.324
7.94X22.86 7.94 22.86 8.74
7.991X10.566 7.991 10.566 4.08
8X13.79 8 13.79 5.36
8X30 8 30 11.766
8X40 8 40 15.53
8X60 8 60 23.37
8X70 8 70 27.27
8X80 8 80 31.18
8.05X15.82 8.05 15.82 6.23
9.715X11.38 9.715 11.38 6.544
10X30 10 30 18.19
10X40 10 40 24.27
10X50 10 50 30.37
10X60 10 60 36.45
10X70 10 70 42.58
10X80 10 80 48.67
10X90 10 90 54.76
10X100 10 100 60.85
12X60 12 60 52.981
12X80 12 80 70.728

Pin

1.78X9.4 1.78 9.4 0.18
1.8X6 1.8 6 0.117
1.8X25 1.8 25 0.493
2.0X7.8 2 7.8 0.191
2.5X6.8 2.5 6.8 0.295
2.5X11.8 2.5 11.8 0.443
2.97X13.8 2.97 13.8 0.748
2.99X13.8 2.99 13.8 0.751
3X5.2 3 5.2 0.302
3X6 3 6 0.312
3X14 3 14 0.731
3X18 3 18 0.967
3X20 3 20 1.054
3X42 3 42 2.31
3.01X12.8 3.01 12.8 0.708
3.5X9 3.5 9 0.659
3.505X21.8 3.505 21.8 1.639
3.97X6.35 3.97 6.35 0.607
4X4 4 4 0.385
4X8.8 4 8.8 0.852
4X10 4 10 0.973
4X11.2 4 11.2 1.081
4X13.8 4 13.8 1.331
4X15.8 4 15.8 1.524
4X18.7 4 18.7 1.838
4X21.5 4 21.5 2.08
4X21.8 4 21.8 2.136
4.02X6.5 4.02 6.5 0.638
5X5 5 5 0.755
5X5.6 5 5.6 0.851
5X5.99 5 5.99 0.91
5X8 5 8 1.217
5X12.8 5 12.8 1.931
5X17 5 17 2.574
5X18 5 18 2.711
5X20.6 5 20.6 3.109
5X38 5 38 5.903
5.2X18.6 5.2 18.6 3.07
5.2X25 5.2 25 4.14
5.5X5.99 5.5 5.99 1.1
5.57X11 5.57 11 2.091
6X10 6 10 2.186
6X11.5 6 11.5 2.58
6X19.5 6 19.5 4.21
6X21 6 21 4.628
6X25.8 6 25.8 5.662
6X29 6 29 6.39
6X45.5 6 45.5 10.064
6X53 6 53 11.744
7X17.5 7 17.5 5.16
7X48.5 7 48.5 14.652
7X50 7 50 15.09
8X14 8 14 2.403
8X30 8 30 11.764
8X35 8 35 13.724
8X38.7 8 38.7 15.25
8X40 8 40 15.698
8X42.5 8 42.5 16.75
8X45 8 45 17.668
8X50 8 50 19.64
8X55 8 55 21.598
8X60 8 60 23.572
8X65 8 65 25.542
8X70 8 70 27.516
8X80 8 80 31.46
8X100 8 100 39.33
9X90 9 90 44.602
10X40 10 40 24.529
10X50 10 50 30.691
10X60 10 60 36.482
10X70 10 70 42.994
10X80 10 80 49.156
10X116 10 116 71.521
11.25X19.4 11.25 19.4 11.1
12X14 12 14 3.803
12X63.5 12 63.5 55.99
13X38 13 38 20.46
13X38.2 13 38.2 20.58
13X39 13 39 21.022
13X72 13 72 49.697
14X39 14 39 20.401
14X41 14 41 24.3
14X41.5 14 41.5 24.5
14X43 14 43 25.502
14X47.5 14 47.5 28.111
15X40 15 40 30.631
15X40.5 15 40.5
15X42 15 42 23
15X49.9 15 49.9 45.423
16X46.5 16 46.5 38.702
16X51 16 51 42.213
16X64 16 64 100.3
19X50 19 50 111.275
28X53 28 53 252.311
