Chrome Steel One Way Clutches CSK25PP C0 C2 C3 C4 C5 Clearance 84836000 Drawn Cup Needle Roller Clutch
Chrome Steel One Way Clutches CSK25PP C0 C2 C3 C4 C5 Clearance 84836000 Drawn Cup Needle Roller Clutch
Chrome Steel One Way Clutches CSK25PP C0 C2 C3 C4 C5 Clearance 84836000 Drawn Cup Needle Roller Clutch
Chrome Steel One Way Clutches CSK25PP C0 C2 C3 C4 C5 Clearance 84836000 Drawn Cup Needle Roller Clutch
Chrome Steel One Way Clutches CSK25PP C0 C2 C3 C4 C5 Clearance 84836000 Drawn Cup Needle Roller Clutch
Chrome Steel One Way Clutches CSK25PP C0 C2 C3 C4 C5 Clearance 84836000 Drawn Cup Needle Roller Clutch
Specifications
Brand Name :
NEKIB OR FUMSB
Model Number :
CSK25PP
Certification :
ISO9001,IATF16949
Place of Origin :
CHANGZHOU,CHINA
MOQ :
100
Price :
0.1-100$ one piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
300kpcs,30days
Delivery Time :
5-8 work days
Packaging Details :
Roll or single box
Number of Row :
Single Row
Precision Rating :
P6
Type :
Roller Type
Sample :
Accept
Material :
Gcr15
HS Code :
84836000
Description

Chrome Steel One way clutches CSK25PP C0/C2/C3/C4/C5 Clearance(drawn cup needle roller clutch)

Decription of products:(drawn cup needle roller clutch)

One-way clutch is composed of outer seat ring, inner seat ring, retainer, wedge block, etc.When the inner seat ring is fixed, the outer seat ring rotates the wedge clockwise without locking, and the outer seat ring can rotate freely.When the outer seat turns counterclockwise, the wedge lock, the outer seat cannot rotate.

The purpose of the cage is to make the wedge always tilt slightly in the direction of the locking outer ring to enhance the locking function of the wedge.

Product Name
CSK25PP One way clutch bearing with size 25*52*15mm
Material
chrome steel
Size
25*52*15 mm
Grade
p6
Brade
Brgro or OEM

Catalogue of other models:(drawn cup needle roller clutch)

Size

Overrunning

speeds

 Øa Øc

Sprag

space

 emin Ødmin Øbmax

Number

of clips

Number

of sprags

 Weight
+ 0,008 ± 0,013
- 0,005
TKN1[Nm]

nimax

[min-1]

Namax2

[min-1]

 [mm] [mm] [mm] [mm] [mm] [mm] [kg]
DC2222G 63 8600 4300 22.225 38.885 8.33 10 50 15 - 12 0.03
DC2776 119 6900 3400 27.762 44.422 8.33 13.5 58 18 - 14 0.055
DC3034 124 6300 3100 30.34 47 8.33 13.5 62 20 - 14 0.06
DC3175(3C) 159 6000 3000 31.75 48.41 8.33 13.5 63 24 3 16 0.06
DC3809A 275 5000 2500 38.092 54.752 8.33 16 71 29 - 18 0.085
DC4127(3C) 224 4600 2300 41.275 57.935 8.33 13.5 75 32 3 18 0.09
DC4445A 363 4300 2100 44.45 61.11 8.33 16 79 34 - 20 0.095
DC4972(4C) 306 3800 1900 49.721 66.381 8.33 13.5 86 38 4 22 0.1
DC5476A 525 3500 1700 54.765 71.425 8.33 16 92 42 - 24 0.11
DC5476A(4C) 525 3500 1700 54.765 71.425 8.33 16 92 42 4 24 0.13
DC5476B(4C) 769 3500 1700 54.765 71.425 8.33 21 92 42 4 24 0.18
DC5476C(4C) 990 3500 1700 54.765 71.425 8.33 25.4 92 42 4 24 0.2
DC5776A 604 3300 1600 57.76 74.42 8.33 16 98 44 - 26 0.11
DC6334B 806 3000 1500 63.34 80 8.33 21 104 50 - 26 0.175
DC7221(5C) 675 2600 1300 72.217 88.877 8.33 13.5 115 56 5 30 0.14
DC7221B 1279 2600 1300 72.217 88.877 8.33 21 115 56 - 30 0.185
DC7221B(5C) 1279 2600 1300 72.217 88.877 8.33 21 115 56 5 30 0.21
DC7969C(5C) 2038 2400 1200 79.698 96.358 8.33 25.4 124 61 5 34 0.28
DC8334C 2055 2300 1100 83.34 100 8.33 25.4 132 65 - 34 0.27
DC8729A 1250 2200 1100 87.29 103.96 8.33 16 134 67 - 34 0.165
DC10323A(3C)* 1612 1800 900 103.231** 119.891 8.33 16 155 80 3 40 0.205
DC12334C* 4800 1500 750 123.34 140 8.33 25.4 184 96 - 50 0.4
**
DC12388C(11C) 4875 1500 750 123.881 142.88 9.5 25.4 196 96 11 44 0.4

Picture:(drawn cup needle roller clutch)

Chrome Steel One Way Clutches CSK25PP C0 C2 C3 C4 C5 Clearance 84836000 Drawn Cup Needle Roller Clutch
