Compact Cell Signal Booster , Mobile Network Booster Device 2100MHz 35dBm
Compact Cell Signal Booster , Mobile Network Booster Device 2100MHz 35dBm
Compact Cell Signal Booster , Mobile Network Booster Device 2100MHz 35dBm
Compact Cell Signal Booster , Mobile Network Booster Device 2100MHz 35dBm
Compact Cell Signal Booster , Mobile Network Booster Device 2100MHz 35dBm
Compact Cell Signal Booster , Mobile Network Booster Device 2100MHz 35dBm
Specifications
Brand Name :
vodasafe
Model Number :
TE2135B01
Place of Origin :
China
MOQ :
1pcs
Packaging Details :
Neutral Packing Carton Box
Frequency Range :
Downlink:2110-2170MHz;
Gain :
(Uplink)Gp≥80dB; (Downlink):Gp≥85dB;
Output Power :
≥35dBm;
Pass band ripple :
≤4dB; ≤0.5μs
Description

2100MHz 35Dbm Cellphone Signal Booster/5W High Power 3GMobile Phone Signal Amplifier

Brief Description:

2100MHz Pico-Repeater is intended to strengthen the signal of 2100MHz mobile phone in the buildings. Ideal for use in areas where the 2100MHz signal is weak to cause Call dropout or Cant connection. The device improves the voice calls and data VOICE GPRS and EDGE (depends of the signal operator).

Features:

1. High system gains.

2. Full duplex and double-end design, external power supply, and convenient installation.

3. ALC technology with auto-steady function adopted.

4. Provide power indication and uplink and downlink indications.

5. With the amplified linear power, the inter-modulation an spuriousness are suppressed effectively.

6. The reliability conforms to GB6993-86 standards.

7. The electromagnetic compatibility conforms to ETS300 609-4 standards.

Applicable place:

It can be applied in Building rooms there have weak signal of mobile.

Specification:

Frequency Range

Uplink:1920-1980 MHz;

Downlink:2110-2170MHz;
Gain (Uplink)Gp≥80dB; (Downlink):Gp≥85dB;
Output Power ≥35dBm;
Pass band ripple ≤4dB;
Guard band rejection (BW-60dB) ≤42MHz;
(BW-70dB) ≤45MHz;
I/O impedance 50Ω/N Connector;
I/O return loss ≤-10dB
Noise figure ≤-8dB
Intermodulation attenuation (Po=13dBm) ≤-40dBm
Transmission ≤0.5μs
Ambient -10℃-50℃
Power supply AC110-220V±10%/45-55Hz;
Size 148mm×106mm×33mm;
Reliability To the GB6993-86 standard
Electromagnetic To the ETS300 694-4 standard;
Function a) Power supply LED denote
b) Export power LED denote

Order Information:

Pico-Repeater 3G2100MHz TE-2135B:Outputpower 35dBm /Gain 85dB Cover area 3500-4000 square meters;

Package contents:

1 pcs booster

1 set power supply

1 pcs user manual

1 set installation screws
