20dBm 900MHz Cellphone Signal Amplifier , Fixed Home Indoor Using Signal Amplifier
20dBm 900MHz Cellphone Signal Amplifier , Fixed Home Indoor Using Signal Amplifier
20dBm 900MHz Cellphone Signal Amplifier , Fixed Home Indoor Using Signal Amplifier
20dBm 900MHz Cellphone Signal Amplifier , Fixed Home Indoor Using Signal Amplifier
20dBm 900MHz Cellphone Signal Amplifier , Fixed Home Indoor Using Signal Amplifier
20dBm 900MHz Cellphone Signal Amplifier , Fixed Home Indoor Using Signal Amplifier
Specifications
Brand Name :
vodasafe
Model Number :
TE92001
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union,
Supply Ability :
5000pcs Per Month
Delivery Time :
3-5Working Days After Payment
Packaging Details :
Neutral Packing Carton Box
Uplink: :
890-915MHz;
Downlink: :
935-960MHz
GSM Uplink Gp :
55dB;
GSM Downlink :
Gp≥60dB
Output Power :
≥20dBm
Pass band ripple :
GSM≤5dB
Description

20Dbm 900MHz Cellphone Signal Amplifier/Fixed Home Indoor Using Signal Amplifier

Brief Description:

900MHz Pico-Repeater is intended to strengthen the signal of 900MHz mobile phone in the buildings. Ideal for use in areas where the 900MHz signal is weak to cause Call dropout or Cant connection. The device improves the voice calls and data VOICE GPRS and EDGE (depends of the signal operator)

Features:

  1. High system gains.
  2. Full duplex and double-end design, external power supply, and convenient installation.
  3. ALC technology with auto-steady function adopted.
  4. Provide power indication and uplink and downlink indications.
  5. With the amplified linear power, the inter-modulation an spuriousness are suppressed effectively.
  6. The reliability conforms to GB6993-86 standards.
  7. The electromagnetic compatibility conforms to ETS300 609-4 standards.

Applicable place:

It can be applied in Building rooms there have weak signal of mobile.

TE-920 Specification:

Frequency Range (Uplink: 890-915MHz; Downlink: 935-960MHz);
Gain TE-920 (GSM Uplink) Gp≥55dB; (GSM Downlink) Gp≥60dB
Output Power TE-920 ≥20dBm
Pass band ripple GSM≤5dB
Guard band rejection GSM (BW-60dB) ≤42MHz
GSM (BW-70dB) ≤45MHz
I/O impedance 50Ω/N Connector
I/O return loss ≤-8dB
Noise figure ≤-8dB
Inter-modulation attenuation(Po=13dBm) ≤-40dBm
Transmission ≤0.5μs
Ambient -10℃-50℃
Power Supply AC110-220V±10%/45～55Hz
Size 148mm×106mm×33mm
Reliability To the GB6993-86 standard
Electromagnetic To the ETS300 694-4 standard
Function

a) Power supply LED denote

b) Export power LED denote

20dBm 900MHz Cellphone Signal Amplifier , Fixed Home Indoor Using Signal Amplifier
