UTP Cat5e 4 pairs 24awg Solid bare copper Lan Cable 305m Pull Box
UTP Cat5e 4 pairs 24awg Solid bare copper Lan Cable 305m Pull Box
UTP Cat5e 4 pairs 24awg Solid bare copper Lan Cable 305m Pull Box
UTP Cat5e 4 pairs 24awg Solid bare copper Lan Cable 305m Pull Box
UTP Cat5e 4 pairs 24awg Solid bare copper Lan Cable 305m Pull Box
UTP Cat5e 4 pairs 24awg Solid bare copper Lan Cable 305m Pull Box
UTP Cat5e 4 pairs 24awg Solid bare copper Lan Cable 305m Pull Box
UTP Cat5e 4 pairs 24awg Solid bare copper Lan Cable 305m Pull Box
Specifications
Brand Name :
H-LIN
Model Number :
HL-CAT5e UTP
Certification :
CE/ROHS/IOS9001
Place of Origin :
Shenzhen China
MOQ :
50 rolls
Price :
negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
80000 rolls per month
Delivery Time :
Shipped within 2 weeks after payment
Packaging Details :
305m/roll, 500m/roll,, 1000ft/box, 1 roll/box, 2 boxes/caton
Number of Conductor :
8
Conductor Material :
Solid Bare Copper
Conductor Dia(mm) :
0.51
Jacket :
PVC/LSZH
Jacket Color :
Medium Grey/Blue/According to the requires
Shield :
Unshielded Twisted Pair
Description

UTP Cat5e 4 pairs 24awg Solid bare copper Lan Cable

Products Description

-Electrical Performance (At 100MHz)

1.0-100.0MHz Impenance(ohms) 100±15

1.0-100.0MHz Impendance delay screw(ns/100m)＜45

Pair To Ground Capacitance Unbalance(PF/100m)330Max

Conductor DC resistance 20%(ohms/km)＜93.8

Resistance Unbalance(%) 5

Test object jacket

Test Material PVC

Before Tensile strength(Mpa) ≥13.8

Aging Elongation(%) ≥100

Aging conditon(C xhrs) 100×240

After Tensile strengh(Mpa) ≥85% of unaged

After Elongation(%) ≥50% of naged

Cold bend(-20±2℃×4 hrs) No crock

Cable Data

Model CAT5e UTP Lan Cable
AWG 24AWG
Conductor Material Solid Bare Copper
Diameter(mm) 0.51
Insulation Material PE
Diameter(mm) 0.91
Core color 1 white-blue/blue 2 white-orange/orange
3 white-green/green 4 white-brown/brown
Sheath Material PVC/LSZH
Color Medium Grey/Black /According to the requires

Construction Show

UTP Cat5e 4 pairs 24awg Solid bare copper Lan Cable 305m Pull Box

Product Show

UTP Cat5e 4 pairs 24awg Solid bare copper Lan Cable 305m Pull Box

UTP Cat5e 4 pairs 24awg Solid bare copper Lan Cable 305m Pull Box
