PVC Blue Gigabit Ethernet Cat6 Network Cable UTP CE ROHS ISO
PVC Blue Gigabit Ethernet Cat6 Network Cable UTP CE ROHS ISO
Specifications
Brand Name :
WONTERM
Model Number :
WT6803
Certification :
CE/FCC/UL/ROHS
Place of Origin :
China
MOQ :
30pcs
Price :
negotiation
Payment Terms :
T/T or western Union
Supply Ability :
2500pcs per month
Delivery Time :
10 working days after received your payment
Packaging Details :
First packed in box and then put two boxes in one Carton
Conductor :
Bare Solid Copper
Number of Conductors :
8
Application :
Indoor
Jacket :
PVC,ROHS,LSZH
Test :
Pass fluk test
Weight :
11.7KG for copper conductor
Description

PVC Blue Gigabit Ethernet Cat6 Network Cable UTP CE ROHS ISO

Specifications:

Specifications

Conductor

Solid Bare Copper

AWG

23AWG

Conductor Diameter (mm)

0.56mm

Pass Fluke

Yes

Jacket

PVC

Color

Blue/Green/Yellow/Black/Gray/Red/White/Purple

Average Thickness(mm)

0.21

Min .Point Thickness(mm)

0.17

Insulation Diameter (±0.02mm)

0.91

Twisting Lay Length(±20mm)

140

Outer Diameter (±0.2mm)

6.0

Rip Cord

Yes

Weight(kg/km)

34

Note: Other specification can be made upon customer requirements.

Description:

1. Twisted pairs with bright color for easy recognition
2. resistance:(f=1-100MHZ)100±15%
3. delay deviation:(max)40ns/100m
4. rated transmission rate:(NVP):72%
5. tensile resistance:(max)250N
6. temperature range:-40°C~+70°C
7. Color Code: Pair 1: white/blue-blue/white Pair 2: white/orange-orange/white
Pair 3: white/green-green/white Pair 4: white/brown-brown/whiteor as per customer's

Applications:

PVC Blue Gigabit Ethernet Cat6 Network Cable UTP CE ROHS ISO

PACKAGE & DELIVERY:


20 feet container: 1050 boxes
40 feet container: 2100 boxes
40 hq container : 2500 boxes


Packing detail:


inner box:305M/1000ft cable-size: 34.5*34.5*19.5 CM ;carton: 61.5*35.8*36.5(3 boxes in a carton)
wooden drum can be supplied.


Delivery Detail:

after checking the box and printing detail, 7-15 days for delivery

PVC Blue Gigabit Ethernet Cat6 Network Cable UTP CE ROHS ISO
