Black LSZH Network Cat5e UTP Cable BC Pass Fluck 4 Pair 0.5mm
Black LSZH Network Cat5e UTP Cable BC Pass Fluck 4 Pair 0.5mm
Black LSZH Network Cat5e UTP Cable BC Pass Fluck 4 Pair 0.5mm
Black LSZH Network Cat5e UTP Cable BC Pass Fluck 4 Pair 0.5mm
Specifications
Brand Name :
WONTERM
Model Number :
WT5803
Certification :
CE/FCC/UL/ROHS
Place of Origin :
China
MOQ :
30pcs
Price :
negotiation
Payment Terms :
T/T or western Union
Supply Ability :
2500pcs per month
Delivery Time :
10 working days after received your payment
Packaging Details :
First packed in box and then put two boxes in one Carton.
Product Name :
UTP Cat5e lan cable
Application :
Indoor
Length :
305m/roll
Nominal Outer Diameter :
0.5mm
Jacket :
LSZH
Temperature Rating :
Inatallation:0~+50°C/Operation:-20~+60°C
Number of Conductors :
8
Packaging :
2 boxes/carton
Description

Black LSZH Network Cat5e UTP Cable BC Pass Fluck 4 Pair 0.5mm

Specifications:

Specifications

Conductor

Solid Bare Copper

AWG

24AWG

Conductor Size

0.5mm/0.51mm etc

Model

indoor cat5e cable

Jacket

PVC

Color

Blue/Green/Yellow/Black/Gray/Red/White/Purple

Number Of Conductor

4pair

Min .Point Thickness(mm)

0.17

Insulation Diameter (±0.02mm)

0.91

Twisting Lay Length(±20mm)

140

Outer Diameter (±0.2mm)

5.2

Rip Cord

Yes

Weight(kg/km)

32

Description:

1, Cable Type: Cat5e

2, Using 24AWG 4 pair UTP network

3, Outer Jacket :PVC/LSZH

4. Cable Length:305m

5. Comply with the UL requirements

6. Two ends terminated with 50u gold plated RJ45 plug by moulding in one motion

7. Pin assignment for RJ45 plug according to T568B wiring scheme.

8. Wirde range of Cord colors for selection according to meet different color coding requirement , in compliant with EIA/TIA 606 standard.

9. Cable color: Blue/Green/Yellow/Black/Gray/Red/White/Purple

10. Package:305m/roll in one carton.

11. Export Market :Global

12. We can produce network cable as per customer's request.

Black LSZH Network Cat5e UTP Cable BC Pass Fluck 4 Pair 0.5mm

Applications:

1. Computer Network Cabling Project.

2. Broadband Network Communication.

3. Digital ISDN Network and ATM 155Mbps Network.

4. Ethernet Network.

5. Audio and Data Transmission.

Black LSZH Network Cat5e UTP Cable BC Pass Fluck 4 Pair 0.5mm


Competitive Advantage:

1. Long transmission distance, small transmission loss, wear resistance, resistance to pressure.

2. We can promise the quality .Because we are using WONTERM which is being produced by our own line 3. WONTERM is most important raw material of another product we are producing now. That means we must produce best quality cable to support our factory.
