24-Port Cat 5e Unshielded Patch Panel Fluke Test UTP with Back Bar

Specifications:

Number of Ports: 24 ports,Krone and 110 dual IDC RJ 45
Performance level: TIA/EIA-568-B.2-1 Category 5e Channel requirements
Port and panel identification: TIA/EIA-606-A labeling standards
Jack housing-polyphelyene oxide, 94V-0 rated
IDC blocks- polyphelyene oxide, 94V-0 rated
Jack contacts-pins: 3,15,30,50 micro (u) inches gold over nickel plating
Dielectric withstanding voltage: 1000 volt maximum.
Panel: Metallic panel black
IDC Block: 110 IDC for 22-26 AWG, fire Approved ABS-UL-94V0
Durability: IDC blocks 200 termination cycles.
Universal wiring scheme T568A and T568B wiring scheme clearly identified on universal label
Patch panels are supplied with T568A and T568B wiring configurations.

Product Description:

1. Meet or exceed Cat. 5E EIA/TIA. 2 Standard
2. Front Panel: 1.5mm thickness Matallic Panel(SPCC).
Painting on surface
3. Plastic Frame: Fireproof PC/ABS UL-94Vo
4. RJ45 jack housing: Fireproof PBT UL-94Vo
5. RJ45 Jack insert: Housing-Fire proof PBT UL-94Vo
Contact- 8P8C Phosper bronze with 3 μ , gold plated.
6. PCB: FR-4/1.6MM UL-94Vo
7. IDC: Body- Fireproof PC/ABS UL-94Vo
Pin: - Phosphor bronze and Tined
8. Label Color Code: T568A/B
9. IDC Terminal: For 22-26 AWG cable
10. High reliability and superior performance
11. RJ45 Jack life: 750 times Min
12. IDC life: 200 times min

Application

1. Entire high-carbon steel outer frame, with plastic powder cladding.
2. RJ45 jack frame material: PBT, golden clad phosphor bronze pins; Shielding shell
of the RJ45 jack; Brass housing with nickel plate; IDC clip: Tinned phosphor
bronze pins.
3. Fitting for 22AWG/23AWG/24AWG cables, Punching dependability: 750 times.
4. Cabling sequence: T568A & B.
5. Punching tools: Standard 110 or LSA type punching tools.
6. Testing condition of transmitting capability: 500MHz.
