Specifications
Brand Name :
H3C
Model Number :
H3C S6720-54c-Ei-48s-AC Swithes
Place of Origin :
Fujian, China
Price :
$1,300.00/pieces 1-9 pieces
MOQ :
1 unit
Private Mold :
NO
Products Status :
Stock, Used, Stock
Ports :
≥ 48
Transmission Rate :
10/100/1000Mbps
Function :
LACP, SNMP
Communication Mode :
Full-Duplex & Half-Duplex
Switch Capacity :
56 Gb/s
Product Name :
H3C S6720-54c-Ei-48s-AC Swithes
Type :
Rack
Description
Products Description
Huawei S6720-54c-Ei-48s-AC10/100/1000Mbps LACP Ethernet Switch 48 Port Swithes for Seamless Network Connectivity
H3C S6720-54c-Ei-48s-AC Swithes
H3C S6720-54c-Ei-48s-AC Swithes
Selling Units:Single item
Single package size:65*40*25cm
Single gross weight:15.000 kg
Item
H3C S6720-54c-Ei-48s-AC Swithes
Memory (RAM)
2 GB
Flash
512 MB in total. To view the available flash memory size, run the display version command.
Mean time between failures (MTBF)
79.39 years (without card)
Mean time to repair (MTTR)
2
Availability
> 0.99999
Service port surge protection
NA
Power supply surge protection
* Using AC power modules: ±6 kV in differential mode, ±6 kV in common mode
* Using DC power modules: ±1 kV in differential mode, ±2 kV in common mode
Dimensions (H x W x D)
* Basic dimensions (excluding the parts protruding from the body): 44.4 mm x 442.0 mm x 424.7 mm (1.75 in. x 17.4 in. x 16.72
in.)
* Maximum dimensions (the depth is the distance from ports on the front panel to the handle on the rear panel): 44.4 mm x 442.0
mm x 451.8 mm (1.75 in. x 17.4 in. x 17.79 in.)
Weight (with packaging)
10.2 kg (22.49 lb)
Stack ports
* Any 10GE SFP+ ports (a maximum of 16 physical ports)
* Any 40GE QSFP+ ports (a maximum of 6 physical ports)
RTC
Supported
RPS
Not supported
PoE
Not supported
Rated voltage range
100 V AC to 240 V AC, 50/60 Hz
-48 V DC to -60 V DC
Maximum voltage range
90 V AC to 264 V AC, 47 Hz to 63 Hz
-38.4 V DC to -72 V DC
Maximum power consumption (100% throughput, full speed of fans)
296.1 W
Typical power consumption (30% of traffic load, tested according to ATIS standard)
190 W (without card)
Operating temperature
0°C to 45°C (32°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)
NOTE:When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the
altitude increases by 220 m (722 ft.).
Storage temperature
-40°C to +70°C (-40°F to +158°F)
Noise under normal temperature (27°C, sound power)
< 72.1 dB(A)
Relative humidity
5% to 95%, noncondensing
Operating altitude
0-5000 m (0-16404 ft.)
Certification
* EMC certification
* Safety certification
* Manufacturing certification
