UNS N05500 Monel K500 Welded Pipe for Cold Cryogenic Treatment and Electrical Heating Elements
UNS N05500 Monel K500 Welded Pipe for Cold Cryogenic Treatment and Electrical Heating Elements
UNS N05500 Monel K500 Welded Pipe for Cold Cryogenic Treatment and Electrical Heating Elements
UNS N05500 Monel K500 Welded Pipe for Cold Cryogenic Treatment and Electrical Heating Elements
Specifications
Brand Name :
DINGSCO
Model Number :
According to customers' requirements
Certification :
ISO 9001:2015,PED 2014/68/EU,API 6A,API-20B,TSG,NORSOK
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
Negotiable
Delivery Time :
(Sample order) 7 days
Packaging Details :
According to customers' requests
Uns :
N05500
Manufacturing Progress :
Welded Pipe / Seamless Pipe
Package :
Woven Packing
Specifications :
Cunstomizable
Material :
Nickel Alloy
Surface :
Annealed, Pickled, Polished or as required
Description

UNS N05500 Monel k500 Wleded Pipe Cold Cryogenic Treating Electrical Heating Elements

1. As a leading Chinese Monel alloy supplier, DINGSCO manufactures and produces different sizes of Monel Alloy K-500 pipes.

2. MONEL® alloy K-500 (UNS N05500 / W.Nr. 2.4375) is a nickel-copper alloy which combines the excellent corrosion resistance of MONEL alloy 400 with the added advantages of greater strength and hardness. The increased properties are obtained by adding aluminum and titanium to the nickel-copper base.

3. Monel K-500 welded pipe & tube is a kind of Monel K-500 pipe or tube formed by bending and welding the Monel K-500 strip or Monel K-500 plate, so the quality of raw materials is very important and decisive. In DINGSCO, we choose the raw materials from big factory and use the most advanced splitting and welding technology to manufacture every Monel K-500 welded pipe & tube. If you need solution annealed Monel K-500 welded pipe or tube to meet the higher demand, we can also anneal the pipe or tube with our online solid solution equipment.

4. Customized Dimensions

  • Outside Diameter (OD) 6~200mm
  • Wall Thickness (THK) 0.35~6.00mm
  • Length (L) 0.5~12m

5. Standards for Monel K-500 Welded Pipe & Tube

  • DIN 17751

6. Chemical Compositions

S C Al Cu Ni
0.01max 0.18max 2.3-3.15 27-33 63min
Si Mn Ti Fe
0.5max 1.5max 0.35-0.85 2max

7. Physical Properties

Density g/cm3 8.44
lb/in3 0.305
Melting Range ℉ 2400-2460
℃ 1315-1350

8. Progress Processing

UNS N05500 Monel K500 Welded Pipe for Cold Cryogenic Treatment and Electrical Heating Elements

UNS N05500 Monel K500 Welded Pipe for Cold Cryogenic Treatment and Electrical Heating Elements
