Alloy 59 with Excellent Corrosion Resistance and High Mechanical Strength

Alloy 59 is a nickel-chromium-molybdenum alloy with an extra-low carbon and silicon content. A-one Alloy is ready to supply high quality Alloy 59 products to customers from worldwide.

Chemical composition (%):

Cr=22.00~24.00, Fe≤1.50, C≤0.010, Mn≤0.50, Si≤0.10, Mo=15.0~16.5, Co≤0.30, Al=0.1~0.4, P≤0.015, S≤0.005 –per ASTM standard

Standards:

ASTM B622 seamless pipe

ASTM B619/626 welded pipe

ASTM B575 sheet and plate

ASTM B574 rod and bar

ASTM B575 strip

ASTM B564 forging

Advantages

• Outstanding resistance to a wide range of corrosive media under oxidising and reducing conditions
• Excellent resistance to pitting and crevice corrosion and freedom from chloride-induced stress-corrosion cracking
• Excellent resistance to mineral acids, such as nitric, phosphoric, sulphuric and hydrochloric acids and in particular to sulphuric and hydrochloric acid mixtures
• Excellent resistance to contaminated mineral acids
• Good corrosion resistance to hydrochloric acid over the whole concentration range up to 40 °C (104 °F).
• Good workability and weldability without susceptibility to post-weld cracking
• Approval for pressure-vessel use with wall temperatures of –196 to 450 °C (– 320 to 840 °F)
• Approved in NACE Standard MR0175, to the highest Level VII for sour gas service

Applications

• Components in organic processes involving chlorides, particularly when acid chloride catalysts are employed
• Digesters and bleaching plants in the pulp and paper industry
• Scrubbers, reheaters, dampers, wet fans and agitators for incinerator gas and flue gas desulphurisation (FGD)
• Equipment and components in sour gas service
• Reactors for acetic acid and acetic anhydride
• Sulphuric acid coolers
