TS450 Thermal Imaging Gun Sight With 400*300 IR Resolution And 50mm Focal Length
TS450 Thermal Imaging Gun Sight With 400*300 IR Resolution And 50mm Focal Length
TS450 Thermal Imaging Gun Sight With 400*300 IR Resolution And 50mm Focal Length
TS450 Thermal Imaging Gun Sight With 400*300 IR Resolution And 50mm Focal Length
TS450 Thermal Imaging Gun Sight With 400*300 IR Resolution And 50mm Focal Length
TS450 Thermal Imaging Gun Sight With 400*300 IR Resolution And 50mm Focal Length
TS450 Thermal Imaging Gun Sight With 400*300 IR Resolution And 50mm Focal Length
TS450 Thermal Imaging Gun Sight With 400*300 IR Resolution And 50mm Focal Length
Specifications
Place of Origin :
China
Brand Name :
OEM, ODM All Available
Certification :
CE,FC,RoHS
MOQ :
10
Delivery Time :
3~7
Payment Terms :
T/T. L/C, Western Union, Money Gram
Supply Ability :
30000PCS/Month
Model Number :
TS450
Spectral :
8μm～14μm
NETD :
≤50mk
Focal Length :
50mm F1.2
FOV :
7.5°×5.6°
Magnification :
3.3~13.2×
Size :
230*90*75mm
Weight :
≤660g
Description

TS450 Thermal Imaging Gun Sight With 400*300 IR Resolution And 50mm Focal Length

Parameter:

Model TS425 TS435 TS450
Detector
Detector Type 400×300 @17μm, VOx
Spectral 8μm～14μm
NETD ≤50mk
Lens
Focal Length 25mm F1.1 35mm F1.2 50mm F1.2
Focusing Manual Focus
FOV 14.9°×11.2° 10.7°×8.0° 7.5°×5.6°
Display
Display Color 0.39-inch OLED Display, 1024×768
Eyepiece Exit pupil distance 48mm, eyepiece magnification 14×
Magnification 1.6~6.4× 2.3~9.2× 3.3~13.2×
Video Output System PAL 50Hz
External Video Display Full color video output by external interface, with menu
Imaging
Frame Rate 50Hz
Digital Zoom 2×,4×
Color Palettes White Hot, Black Hot, Red Hot 1, Red Hot 2, Red Hot 3, Green Hot, Blue Hot
Picture-in-picture On/off,the position is adjustable
Functions
hotspot tracking Yes
Compensation Modes Auto Compensation / Shutter Compensation / Scene Compensation
Calibration 25m/50m/100m
Stadiametric rangefinder 1.8m/0.5m/0.25m
Gun Types Selection 6 Types
Power Supply
Battery Type Interchangeable Li-ion battery 18650 x 1, Non-rechargeable on the device
Battery Operating Time ≥3H(Standard low temp battery,Observation status only)
≥5H(Panasonic 3400mah standard 18650 battery,Observation status only)
Interface
Video Interface Lemo
Environmental Characteristics
Operating Temperature -40°C-50°C
Shock 500G/1ms
Encapsulation IP67
Certificate RoHS,CE
Weight & Dimensions
Weight(excl battery) 660g 660g 720g
Dimensions 230mm×90mm×75mm 230mm×90mm×75mm 250mm×90mm×75mm
Package Contents
Standard Lens cap,battery,Charger,Video cable,
Pick-up gun rack,Hard transport case,User Manual
Detection Range
Human:1.8m×0.5m 700m 1000m 1400m
Vehicle:2.3m×2.3m 1700m 2400m 3000m
Recognition Range
Human:1.8m×0.5m 350m 500m 700m
Vehicle:2.3m×2.3m 700m 1000m 1400m





Features:

1 With a 400x300 pixel TEC metal-encapsulated thermal detector, it can detect further distances and capture sharper, vivid images.

2. The TS thermal sight also has the characteristics of small size, waterproof and dustproof, strong shock resistance, strong and durable, and can perform well in any bad weather.
