PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll
PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll
PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll
PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll
PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll
PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll
Specifications
Brand Name :
Chuzhou HH non-woven
Model Number :
HH Meltblown
Certification :
CE
Place of Origin :
Chuzhou China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
For detailed talk
Delivery Time :
For detailed talk
Packaging Details :
wooden case
Product :
1600 M Meltblown Nonwoven Fabric Machine
certificate :
ISO CE
power consumption :
300 - 500 kw / Hr
finished :
meltblown fabric roll
after service :
engineer over sea or online service
screw :
double
inverter :
ABB
transport package :
by sea with stretch film wooden case
Description


PP Meltblown Nonwoven Fabric Making Machine for Mask Filter Fabric

Filter fabric manufacturing machine, melt blown PP non-woven machine
1. Technical data of melt blown nonwovens manufacturing machine.
Material: PP chip MFI 1200-1400
Fabric uses: medical masks, clothing thermal insulation materials, car covers, linoleum, baby diapers, gas filters, disposable products, etc.
The production line is suitable for PP chips as raw material input, extrusion, spinning, trickle quenching, netting, winding, cutting and other processes as required, and then packaging, storage and delivery.
2. Technical data of melt blown nonwovens manufacturing machine.
-Raw material: Polypropylene
-Process: melt flow
-Optical fiber GSM: 10g / sm-200g / SM
-Available fabric colors: more than 30 kinds
-Embossing: diameter
-Machine consumption: 600kW ~ 1200kW
-Fabric width: from 1.6m to 3.2m
-Voltage: 380V, 50Hz
3. Characteristics of melt blown nonwovens manufacturing machine.
The whole production line is well structured and easy to operate
The whole production line is highly automated
The control components adopt well-known brands, high performance and reliable technology.
The whole line is controlled by PLC and operated by touch screen.
The configuration of main frame and auxiliary equipment can be specially designed and configured according to customer requirements.
4. Application field of melt blown nonwovens manufacturing machine.
Fabric uses: medical masks, clothing thermal insulation materials, car covers, linoleum, baby diapers, gas filters, disposable products, etc.
5. Workflow of melt blown nonwovens manufacturing machine.
flow chart
Raw materials (edge material recovery) - melt extrusion - filter metering - melt flow device - mesh forming machine - winding and slitting machine - finished products
PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll

HHM 1600 m meltblown fabric making line date

Width 1600 M
Gsm 9 - 250 gsm
Output per day 4 - 6Ton
Machine Speed ≦70 m / min
Transformer ≈ 600 KVA
Power Consumption 3000º - 3500º / Ton
Machine Size 18 * 10*10M

Model Effective Width Weight Range Output per day Machine speed Tranformer Power consumption Machine Size
HHM-1.6M 1.6M 15-300G/M2 2-3Ton ≦10-70m/min ≈600KVA 3000º-3500º/Ton 18M*10M*10M
HHM-2.4M 2.4M 15-300G/M2 3-4Ton ≦10-70m/min ≈800KVA 3000º-3500º/Ton 18M*11M*10M
HHM-3.2M 3.2M 15-300G/M2 4.5-5Ton ≦10-70m/min ≈1000KVA 3000º-3500º/Ton 18M*13M*10M


Parts of Melt blown nonwoven fabric production line:
Main extruder→filter→Metering pump→Air heating system→Melt blown sprayer (ENKA sprayer)→Web former→Winder→Slitter

Melt blown process and technical flow chart:
Raw material →Melting→Filtering→Measureing→Air heating→Spraying→Web forming→Winding→Cutting→Final product

PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll
Main machine parts introduce

PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll

Maximum temperature 300 ℃
Max. Output 200 kg / h
Heating zone 8 tod
Perforated length 3,350 mm
HPI 40
Number of holes 5,276
1 Set L/D 10
Capillary diameter 0.3mm
Capillary length 3,600mm


PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll

Aperture (1pc) 90 300 kg / h
The screw L/D of the main extruder 30:1
The screw L/D of the ancillary extruder 15:1


PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll

Air heater
Heating power: 220KW-240KW
Material of tank and pipeline: stainless steel 304
Insulation form: stainless steel seal outside the insulation layer

PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll

Air Blower

It is used to pump, exhaust gas, and to compress the gas, and convert the energy input into the kinetic energy and potential energy of the gas in order to increase the unit energy of the gas.


Precisely CNC center ensure processing accuracy

PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll

PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll
PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll

PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll


Exhibition show

PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll
PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll




PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll

Packaging Details

Nude packing , wooden case is optional.
case packing:Carding machine, lapper and electric boxes wooden case packaged.
Other machines nude packaging.

PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll

PP Spunbond Meltblown Nonwoven Machine Multipurpose For Fabric Roll


FAQ:

1.How can i know your machine has good quality?
You can visit our company and we will see many machines in China,because we also have many customers from local market.
2.What is the delivery time for nonwoven machines as usual?
We need 3-6 month to make your order.
3.Will you inspect my order before shipping?
We accept SGS inspection service and buyer own inspect it,we will pay all expense for buyer visiting.
4.How is your after-sale service and warranty?
we provide 12 month warranty and free door to door engineering service in the period.
Free spare parts replacement and online technical support.
5.How long time for machine installation?
It takes 30-60 days for machine installation as usual.
