CE Certified Meltblown Nonwoven Machine
CE Certified Meltblown Nonwoven Machine
CE Certified Meltblown Nonwoven Machine
CE Certified Meltblown Nonwoven Machine
CE Certified Meltblown Nonwoven Machine
CE Certified Meltblown Nonwoven Machine
Specifications
Brand Name :
Chuzhou HH non-woven
Model Number :
HH Meltblown
Certification :
CE
Place of Origin :
Chuzhou China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
3 line / months
Delivery Time :
90 - 150 days
Packaging Details :
components wood box packaged , machine wrapping with PE film keep cargo safe
Product Name :
Meltblown fabric production line
advantage :
easy operation
type screw :
double twin
number of die :
one
transformer :
600 - 1000 KVA
CE :
yes
packing :
wooden box
port :
Nanjing or Shanghai
Description

easy operation low investment cost effective meltblown fabric production line

What ingredients are used?
PP and base metal, containing anti-oxidation, anti pilling, flame retardant and other additives.
What factors affect the quality of melt blown fabrics?
MFI and resin batch quality of polypropylene
As the best filter layer of the mask, melt blown is a very fine material with many crisscross microfibers. Using melt blown PP material with MFI up to 1500, the finer the melt blown process drawing, the better the filtration performance.
describe
The melting point of raw polypropylene is 166 ℃
Spunbonded polypropylene melt index 28-45 denier spunbonded fiber 1.8-2.5 denier
Melt blown polypropylene melt index 1300-1800 denier, melt blown fiber 1.6-4 microns
CE Certified Meltblown Nonwoven Machine

CE Certified Meltblown Nonwoven Machine

Technical Parameters

Model HHM-1.6m HHM-2.4M HHM-3.2M
Effective Width 1.6 M 2.4 M 3.2 M
Weight Range 18-300 G/㎡ 18-300 G/㎡ 18-300 G/㎡
Out put day 2-3 Ton 3-4 Ton 4.5-5 Ton
Machine Speed ≦70 m/min ≦70 m/min ≦70 m/min
Power Consumption 3000º-3500º/Ton 3000º-3500º/Ton 3000º-3500º/Ton
Machine Size(L*W*H) 18M*10M*10M 18M*11M*10M 18M*13M*10M

Meltblown Making Machine Series

Model

Product Width

(mm)

GSM Range

( g / ㎡ )

Capacity

(kg /day )

Melt blown

(BFE&PFE)
HHM- 1600 1600 15 - 300 200 - 300

BFE 99+

PFE 95+
HHM - 2400 2400 300 - 400
HHM - 3200 3200 450 - 500

Parts of Melt blown nonwoven fabric production line:

Main extruder→filter→Metering pump→Air heating system→Melt blown sprayer (ENKA sprayer)→Web former→Winder→Slitter

Melt blown process and technical flow chart:

Raw material →Melting→Filtering→Measureing→Air heating→Spraying→Web forming→Winding→Cutting→Final product

CE Certified Meltblown Nonwoven Machine

Meltblown non-woven fabric production line components:

Screw extruder---->filter---->metering pump---->heating system---->melt blown box (Kasen)---->netting machine---- >Rewind

(1) Receiving networked device:

Line speed: up to 50m/min

Meltblown receiving adjustment range: 200mm

Installation form: It can be moved horizontally, which is convenient for installation, debugging and maintenance

Driving rate: 1.1KW

(2) Suction net fan:

Power: 75KW,

4. Hot air heating system

(1) Atlas air compressor

Boost pressure: 0.7MPa

Power: 120KW~200KW

(2) Air heater

Heating power: 220KW-240KW

Material of tank and pipeline: stainless steel 304

Insulation form: stainless steel seal outside the insulation layer

5. Electret system.

6. Rack platform device:

Steel structure, easy to disassemble, firm and reliable, including stairs, etc.

7. Die head heating power: about 70kw

8. Electrical control box

CE Certified Meltblown Nonwoven Machine

CE Certified Meltblown Nonwoven Machine

CE Certified Meltblown Nonwoven Machine

CE Certified Meltblown Nonwoven Machine

CE Certified Meltblown Nonwoven Machine

High precisely CNC center

CE Certified Meltblown Nonwoven Machine

CE Certified Meltblown Nonwoven Machine

Exhibition Show

CE Certified Meltblown Nonwoven Machine

CE Certified Meltblown Nonwoven Machine

Packing & shipping

Electrical parts small parts each numbered put in carton or wooden box , large scale machine will nude wrarping with PE film fixed in container keep cargo safe .

CE Certified Meltblown Nonwoven Machine

CE Certified Meltblown Nonwoven Machine

Our Service

1.Pre-sale Service
Employees have a special sense of responsibility and excellent teamwork spirit, so the machine adopts unique and outstanding components, which meet the highest standards of the nonwoven industry.
With the support of modern technology, to provide all customers with the best solution machinery Claim.

2.After-sales Service
Our customer service can answer inquiries.
We only believe that: the best machine with innovative ideas and high-quality after-sales service: "will meet your special requirements."
