3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic
3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic
3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic
3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic
3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic
3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic
Specifications
Brand Name :
Chuzhou HH non-woven
Model Number :
HH Meltblown
Certification :
CE
Place of Origin :
Chuzhou China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
3 line / months
Delivery Time :
90 - 150 days
Packaging Details :
components wood box packaged , machine wrapping with PE film keep cargo safe
Description :
3.2 Meltblown fabric production line
effective width :
3200 mm
Marketing type :
2022 new product
Raw material :
polypropylene granule
Gsm :
270 g
advantage :
fully automatic
weight :
50- 100 ton
capacity :
5000 kg / day
Description

Automatic 3200 PP Meltblown Melt Blown Fabric production line melt blown non woven fabric making machine

About non woven die head

How to clean melt-blown die head cleaning?
Add cleaning agent for ultrasonic cleaning machine. The spinneret is thoroughly immersed in the cleaning agent. The ultrasound was activated and heated to 100℃ for 1.5 hours each time. After cleaning, turn off the heating and ultrasonic cleaning machine.
Take out the spinneret and the spinneret spare parts, and use the dry ice cleaner to blow the spinneret hole to remove the remaining materials in the spinneret hole.
Finally, all spinneret holes are examined with a digital electron microscope to ensure there is no residual material in the spinneret holes.
How often should mold heads be cleaned?
According to mold and spinneret clogging condition. It is generally cleaned every 10-15 days, if the material is clean, there is less impurity, if only a few pinholes are blocked, the cleaning cycle can be extended, a simple treatment with (acupuncture) Silver needle can be used, which can reduce the number of cleaning.
3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic

HHM-3200 Melt Blown line data

Effective Width 3200mm
Weight Range 15-300 g / ㎡
Out put day 4.5 -5 ton
Machine speed 10-70 m/ min
Transformer ≈1000 KVA
Power consumption 3000º - 3500º / ton
Machine Size 18 *13 *10 M

Description Melt blown machine raw material

Raw materials pp polypropylene Melting point 166℃
Spunbond pp melt index 28-45 Denier of spunbond fiber 1.8-2.5 denier
Meltblown pp melt index 1300-1800 Denier of melt blown fiber 1.6-4 microns

3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic

Technical Parameters

Model HHM-1.6m HHM-2.4M HHM-3.2M
Effective Width 1.6 M 2.4 M 3.2 M
Weight Range 18-300 G/㎡ 18-300 G/㎡ 18-300 G/㎡
Out put day 2-3 Ton 3-4 Ton 4.5-5 Ton
Machine Speed ≦70 m/min ≦70 m/min ≦70 m/min
Power Consumption 3000º-3500º/Ton 3000º-3500º/Ton 3000º-3500º/Ton
Machine Size(L*W*H) 18M*10M*10M 18M*11M*10M 18M*13M*10M

Meltblown Making Machine Series

Model

Product Width

(mm)

GSM Range

( g / ㎡ )

Capacity

(kg /day )

Melt blown

(BFE&PFE)
HHM- 1600 1600 15 - 300 200 - 300

BFE 99+

PFE 95+
HHM - 2400 2400 300 - 400
HHM - 3200 3200 450 - 500

Meltblown non-woven fabric production line components:
Screw extruder---->filter---->metering pump---->heating system---->melt blown box (Kasen)---->netting machine---- >Rewind
Meltblown production process flow chart:
Raw Material----> Melt Extrusion----> Filtration----> Metering----> Air Heating Compression----> Melt Blown----> Web Formation----> Winding

3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic

Meltblown non-woven fabric production line components:

Screw extruder---->filter---->metering pump---->heating system---->melt blown box (Kasen)---->netting machine---- >Rewind

(1) Receiving networked device:

Line speed: up to 50m/min

Meltblown receiving adjustment range: 200mm

Installation form: It can be moved horizontally, which is convenient for installation, debugging and maintenance

Driving rate: 1.1KW

(2) Suction net fan:

Power: 75KW,

4. Hot air heating system

(1) Atlas air compressor

Boost pressure: 0.7MPa

Power: 120KW~200KW

(2) Air heater

Heating power: 220KW-240KW

Material of tank and pipeline: stainless steel 304

Insulation form: stainless steel seal outside the insulation layer

5. Electret system.

6. Rack platform device:

Steel structure, easy to disassemble, firm and reliable, including stairs, etc.

7. Die head heating power: about 70kw

8. Electrical control box

3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic

3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic

3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic

3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic

3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic

3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic

High precisely CNC center

3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic

3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic

Exhibition Show

3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic

3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic

Packing & shipping

Main machine parts will be packed with wooden cases.Electrical parts will be packed with plastic and then packed into wooden cases.For the steel structure they will be packed in bulk into containers.

3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic

3200mm 270gsm PP Meltblown Fabric Production Line Fully Automatic

FAQ

1.Q : Are you a factory or trading company ?

A : We are established in 2009 , has been in onwoven industry for more than ten years .

2.Q: Do you have technical support?

A: yes , we will provide on-site installation service.

3 Q : How does your factory do regarding quality control ?

A: Quality is the most important principle . we always attach great importane to quality controlling from the very beginnging to the very end , our factory has passed CE and ISO certification .

4 Q :How long is you machine’s warrant period .

A : bascily one year warranty , long time service support .
