Touch Screen Non Woven Screen Printing Machine / Automatic Screen Printing Press
Touch Screen Non Woven Screen Printing Machine / Automatic Screen Printing Press
Touch Screen Non Woven Screen Printing Machine / Automatic Screen Printing Press
Touch Screen Non Woven Screen Printing Machine / Automatic Screen Printing Press
Touch Screen Non Woven Screen Printing Machine / Automatic Screen Printing Press
Touch Screen Non Woven Screen Printing Machine / Automatic Screen Printing Press
Touch Screen Non Woven Screen Printing Machine / Automatic Screen Printing Press
Touch Screen Non Woven Screen Printing Machine / Automatic Screen Printing Press
Specifications
Brand Name :
WEIXIN
Model Number :
WX-NWF12010W
Certification :
CE/ISO9001
Place of Origin :
Zhejiang,China(Mainland)
MOQ :
1 SET
Price :
Negotiation
Supply Ability :
20 Set/Sets Per Month
Delivery Time :
30 Working Days
Packaging Details :
Wooden case
Usage :
Non woven fabric,cloth
Color & Page :
Single Color
Max.Printing Area :
1200*1100mm
Max.Web Width :
1250mm
Max. Diameter of Rolls :
800mm
Printing Speed :
700-1500m/h
Non-woven Fabric Thickness :
45-100 GSM
Voltage & Total Power :
380V 3P4N 29kw
Servo Motor :
Delta ,Taiwan
PLC Control :
Delta, Taiwan
Warranty :
12 month
Overall Size :
7500x1800x2200mm
Description

Touch Screen Roll To Roll Automatic Non Woven Fabric Screen Printing Machine

Main Technical Parameters

Model WX-NWF12010W WX-NWF12010ll
Max.Printing Size 1200*1100mm 1200*1100mm
Non-woven Fabric Rolls Width 1250mm 1250mm
Non-woven Fabric Thickness 45g/m^2~100g/m^2 45g/m^2~100g/m^2
Max.Diameter Of Rolls 800mm 800mm
Printing Speed 500-1100m/h 500-800m/h
Voltage&Total Power 380V 3P4N 24KW 380V 3P4N 65KW
Machine Size 10500*1800*1720mm 21500*1800*1720mm
Basic Structure Feeding Part + Printing Part + Drying Part + Collecting Part

Feeding Part + Printing Part + Drying Part + Collecting Part
Weight 2000kg 2000kg
Specifications 1. Automatic feeding printing, drying and collecting. Save labors and overcome restraints caused by weather conditions.
2. With balanced pressure, with high ink thickness. Suitable for printing on high-quality non-woven products.
3. Applied to various sizes of printing screen frames.
4. Big-size printing area to print multiply layouts. Improve work efficiency
Print multiply layouts on big-size printing to improve work efficiency
5. Before and after full page printing, effective space between images can be reduced to minimum 1 cm.
6. High precision of printing controlled by servo motor,
7. Connected with non-woven bag making machine to produce the bag automatically. Greatly improv work efficiency.

Machine Parts Brand

Heating Motor Dedong, Shanghai
Printing Servo Motor Delta, Taiwan
Traction Stepping Motor SOYO, Jiangsu
Reducer Liancheng, Taiwan
Cylinder UNICO, Japan
Magnetic Valve YPC, Korea
Sensor Omron, Japan
Printing Track SBC, Korea
Contactor Schneider, France
Breaker Schneider, France
Button Schneider, France
Switch Mingwei, Taiwan
PLC Delta, Taiwan
Touch-screen Panel Delta, Taiwan
Testing Sensor Futai, Taiwan
Feeding Magnetic-power Controller Zhongxing, Zhejiang
Correction Controller Zhongxing, Zhejiang
Tension Controller Zhongxing, Zhejiang
Collecting Frequency Converter Huichuan, Shanghai

Packing & Devlivery

Touch Screen Non Woven Screen Printing Machine / Automatic Screen Printing Press

Packaging Details: Packing in wooden case & One 40HQ container
Delivery Detail: Within 30 working days after the receipt of 30% deposit
