PLC Control Automatic Non Woven Bag Making Machine For Non Woven Bag
PLC Control Automatic Non Woven Bag Making Machine For Non Woven Bag
PLC Control Automatic Non Woven Bag Making Machine For Non Woven Bag
PLC Control Automatic Non Woven Bag Making Machine For Non Woven Bag
Specifications
Brand Name :
WEIXIN
Model Number :
WX-LT500
Certification :
CE
Place of Origin :
Zhejiang ,China (Mainland)
MOQ :
1SET
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
25 sets/month
Delivery Time :
30 working days
Packaging Details :
shrink film and wooden case packing
Material :
Non Woven & Laminated Non woven
Bags Type :
Laminated Non woven box bag ,Non woven box bag
Production Speed :
45-70 Pcs/min
Weight :
9000KGS
Voltage :
380V 50HZ,3 Phase
After Sales Service :
Engineer available to overseas
Description

PLC Control Automatic Non Woven Bag Making Machine For Non Woven Bag Handle Bag

Main Machine Description

1. Schematic diagram

PLC Control Automatic Non Woven Bag Making Machine For Non Woven Bag

2.Process flow

Auto non woven roll feeding-> Auto tension control, centralization-> Mouth folding-> Handle welding-> Handle folding-> Online impression-> Bag forming-> Bag folding -> Bag collection.

Features

1.Leader is newly researched and developed on 2014, patent No.: 201420080547.2

2.Leader is concentrated in Non woven box bag manufacturing,use nonwoven fabric and nonwoven laminated fabric as raw material.

3.Leader can perform good with few labour,higher efficient&lower cost, it’s the most competitive machine in nonwoven bag making.

4.Nonwoven bag have more advantages when compare with nonwoven sewing bag and paper bag.

Advantage

1.Ultrasonics own production,72 hrs destructive inspection.

2. Independent R&D Centre and CNC production
3. Automatic feeding deviation rectifying device. Machine adopts motor for stable feeding and photocell for deviation rectifying. It will stop automatically without fabric.
4. Tracking & Creasing Device for color tracking and side creasing.
5. Operation Panel. Computer control,automatic feeding and counting.
6. Double Servo Motor(Delta Taiwan) Material Drawing Device. Double servo motor can adjust the level of fabric and die, in order to control the uniformity of bag mouth and increase machine speed.

Main Technical Data

SN Item Specification
1 Roller width 50-1150mm
2 Bag making speed 60pcs/min
3 Bag length 180-450mm
4 Bag width 240-500mm
5 Gusset 90-200mm
6 Power supply 380V
7 Total power 40KW-60KW
8 Rated power 8KW-10KW
9 Overall size L 9000* W 4000* H 2500mm
10 Weight of Machine 9000KGS (40HQ*1)

Bag Sample

PLC Control Automatic Non Woven Bag Making Machine For Non Woven Bag
