W90 Cu10 Round Alloy Tungsten Copper Bar Rod Heat Resistant In Aerospace
W90 Cu10 Round Alloy Tungsten Copper Bar Rod Heat Resistant In Aerospace
Specifications
Model Number :
Tungsten Copper Bar
MOQ :
Negotiate
Price :
Negitionable
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
1000sets/month
Delivery Time :
30 days after receiving down payment
Packaging Details :
Standard export cartons
Name :
Tungsten Copper Bar
Material :
Tungsten Copper Alloy
Shape :
Bar&Rod
Application :
Electrical
Grade :
W90/Cu10
Feature :
Heat Resistant
Description

W90/Cu10 Round Tungsten Copper Bar Heat Resistant

Tungsten Copper Bar Characters:

1. Better heat resistant;

2. better ablate-resistant;

3. High intensity

4. High density;

5. Excellent thermal and electrical conductivity;

6. easy to be machined.

Tungsten Copper Bar Parameters

Class

Chemical Composition (wt%)

Density

Hardness

Resistivity

IACS

Bending Strength

Cu

Total Impurities≤

W

g/cm3 ≥

HB Kgf/mm2 ≥

μΩ.cm ≤

% ≥

MPa ≥

W50/Cu50

50±2.0

0.5

Balance

11.85

115

3.2

54

—

W55/Cu45

45±2.0

0.5

Balance

12.3

125

3.5

49

—

W60/Cu40

40±2.0

0.5

Balance

12.75

140

3.7

47

—

W65/Cu35

35±2.0

0.5

Balance

13.3

155

3.9

44

—

W70/Cu30

30±2.0

0.5

Balance

13.8

175

4.1

42

790

W75/Cu25

25±2.0

0.5

Balance

14.5

195

4.5

38

885

W80/Cu20

20±2.0

0.5

Balance

15.15

220

5

34

980

W85/Cu15

15±2.0

0.5

Balance

15.9

240

5.7

30

1080

W90/Cu10

10±2.0

0.5

Balance

16.75

260

6.5

Tungsten Copper Bar Features

Tungsten-copper alloy has a wide range of applications, most of which are used in aerospace, aviation, electronics, electric power, metallurgy, machinery, sports equipment and other industries. Secondly, it is also used to manufacture the contacts of high-voltage electrical switches and high-temperature components such as rocket nozzle throat liner and tail rudder, which are resistant to arc erosion, and also used as electrodes for electrical machining, high-temperature molds and other occasions requiring conductive and thermal conductivity and high-temperature use.

Tungsten Copper Bar Applications

1. Arcing contacts and vaccum contacts in high and medium voltage breakers or vaccum interruptors

2. Electrodes in electric spark erosion cutting machines

3. Electrodes for resistance welding.
