Knurled Metal Sleeve Bearing For Construction Machinery Custom Service Available
Knurled Metal Sleeve Bearing For Construction Machinery Custom Service Available
Knurled Metal Sleeve Bearing For Construction Machinery Custom Service Available
Knurled Metal Sleeve Bearing For Construction Machinery Custom Service Available
Knurled Metal Sleeve Bearing For Construction Machinery Custom Service Available
Knurled Metal Sleeve Bearing For Construction Machinery Custom Service Available
Specifications
Brand Name :
JESENTECH
Model Number :
Non Standard Customization
Certification :
IATF 16949:2016
Place of Origin :
Shenzhen CHINA
MOQ :
1-5 PIECES
Price :
Negotiated price
Payment Terms :
T/T, L/C, Western Union,Paypal etc.
Supply Ability :
3500000 pieces/Month
Delivery Time :
3-7 days
Packaging Details :
General export packaging(PVC Bags+Shockproof cushion+Carton Box+Wood pallet)
Application :
Construction machinery
Material :
stainless steel/copper/brass or customized
Finishing :
as client's requirement
Standard :
IATF16949:2016
Size :
as client's requirement
MOQ :
1 Pieces
Lead Time :
3-7 days
Description

Customized machining according to drawings knurled metal Bushing sleeve for Construction machinery

Affect of bushing

In the moving parts, because of friction and the wear and tear parts for a long time, when the clearance between the shaft and hole wear by a certain amount of time must be replacement parts, so the designers choose in design of low hardness, good abrasion resistance material for collar or bushing, thus reducing shaft and seat wear and tear, when the bushing or replace bushing wear to a certain extent, so that we can save for the cost of replacement of shaft or housing.

Type Material Surface finish Hardness
D size P6 D size m6
BSCPKR BSCMKR SKS3 / 58~61HRC

Knurled Metal Sleeve Bearing For Construction Machinery Custom Service Available

Type P tolerance (g6) L D H Thickness(E) T R D tolerance
Type P (p6) (m6)
(p6) (m6)
BSCPKR BSCMKR		 2 +0.008
+0.002		 5 6 8 10 12 5 9 1.5 2.5 0.8 +0.02
+0.012		 +0.012
+0.004
3 5 6 8 10 12 7 11 2 2.5 0.8 +0.024
+0.015		 +0.015
+0.006
4 +0.012
+0.004		 5 6 8 10 12 15 16 20 8 12 2 3 1
5 5 6 8 10 12 15 16 20 10 14 2.5 3 1
6 5 6 8 10 12 15 16 20 25 10 14 2 3 1
8 +0.014
+0.005		 5 6 8 10 12 15 16 20 25 12 16 2 4 2 +0.029
+0.018		 +0.018
+0.007
10 6 8 10 12 15 16 20 25 15 19 2.5 4 2
12 +0.017
+0.006		 8 10 12 15 16 20 25 30 18 22 3 4 2
13 10 12 15 16 20 25 30 22 26 4.5 5 2 +0.035
+0.022		 +0.021
+0.008
15 12 15 16 20 25 30 25 30 5 5 2
16 12 15 16 20 25 30 26 30 5 5 2
20 +0.020
+0.007		 12 15 16 20 25 30 30 35 5 6 3
25 16 20 25 30 35 35 40 5 6 3 +0.042
+0.026		 +0.025
+0.009

Knurled Metal Sleeve Bearing For Construction Machinery Custom Service Available
