AC220V 1.1kw 105pcs/Min Non Woven Shoe Cover Making Machine
AC220V 1.1kw 105pcs/Min Non Woven Shoe Cover Making Machine
AC220V 1.1kw 105pcs/Min Non Woven Shoe Cover Making Machine
AC220V 1.1kw 105pcs/Min Non Woven Shoe Cover Making Machine
AC220V 1.1kw 105pcs/Min Non Woven Shoe Cover Making Machine
AC220V 1.1kw 105pcs/Min Non Woven Shoe Cover Making Machine
AC220V 1.1kw 105pcs/Min Non Woven Shoe Cover Making Machine
AC220V 1.1kw 105pcs/Min Non Woven Shoe Cover Making Machine
AC220V 1.1kw 105pcs/Min Non Woven Shoe Cover Making Machine
AC220V 1.1kw 105pcs/Min Non Woven Shoe Cover Making Machine
Specifications
Brand Name :
MDK
Model Number :
NB-005
Place of Origin :
China
MOQ :
1 Set
Payment Terms :
T/T, Western Union, MoneyGram, D/P
Supply Ability :
50 Sets Per Month
Delivery Time :
No late than 12 Working Days
Packaging Details :
Wooden Case
Material :
Nonwoven
Material gram :
From 25gsm-45gsm
Elastic :
Double Elastic
Elastic Size :
5mm
Side band :
Nonwoven
Side band Width :
20mm
Side band Gram :
From 30-45gsm
Product Sizze :
Normal 17*40
Ultrasonic :
4-5 Sets
Machine Size :
1802*880*1303mm；1302*706*1030mm
Machine Weight :
550kgs
Description

Nonwoven Shoe Cover Machine

Brief Introduction

  • This machine is special manufacturing equipment for non-woven shoe cover.
  • The processes from inserting raw material, embedding elastic band, folding, fusion cutting shape to finished product could be automatically completed .
  • The machine utilizes frequency conversion stepless speed control., also can operate, maintain and modify conveniently.

Structure Diagrammatic Sketch

AC220V 1.1kw 105pcs/Min Non Woven Shoe Cover Making Machine

1. Driving Fraction

2. fusion cutting part

3 .non-woven fabric

4. shelf

5. ultrasonic wave

6. elastic band welding part

7. feeding wheel

8. electric cabinet

9. elastic band

10 .ultrasonic wave control cabinet

Machine Feature

1. This machine adopts high-strength aluminum plate ,rack and components which are experienced high quality surface treatment. solid and durable,nice appearance and operating reliability

2.Ultrasonic welding automatically

3 Adopting frequency speed control and electronic counting , efficient energy conservation

4. Steady operation,smallest vibration and lowest noise

5. Convenient transport,hoisting and installation.

Main Technical Parameters

Type NB-005
Capacity (pieces/min) 100-120
Power Source AC220V 1PH 50Hz
Motor Capacity KW 1.1
Gear Reduction Ratio: 1:10
Ultrasonic Power KW 3.2KW
Shoe cover size(L×W mm) 410×(150-170)
Shoe cover elastic size 30-40#
Dimensions (L×W×H mm) 1900×1700×1560
Operating environment Asepsis and purifying
Ambient Temperature -10—+26°

AC220V 1.1kw 105pcs/Min Non Woven Shoe Cover Making Machine

After Service

1. Manuals / Videos of machine installation, adjusting,setting, maintenance are available for you.

2. If any problems happenandyou can not find out the solutions, Telecom or Online face to face communication available 24 hours.
3. ICT engineers &technicians are available to send to your countries for services if you agree to pay the expenditure.
4. The machine will have a 1-year warranty for the machine.
