High Air Pressure DTH Drilling Tools 8 Inches 35 Degree Down The Hole Hammer Bits
High Air Pressure DTH Drilling Tools 8 Inches 35 Degree Down The Hole Hammer Bits
High Air Pressure DTH Drilling Tools 8 Inches 35 Degree Down The Hole Hammer Bits
High Air Pressure DTH Drilling Tools 8 Inches 35 Degree Down The Hole Hammer Bits
Specifications
Brand Name :
OED/OEM
Model Number :
3 inch 4 inch 5 inches 6 inches
Certification :
ISO 9001 2008
Place of Origin :
China
MOQ :
50pcs
Price :
Negotiable
Delivery Time :
20 days
Packaging Details :
Wooden Box
Color :
Yellow/Golden/Red/Black/Customized
Material :
Tungsten Carbide
Dimension :
3 inch 4 inch 5 inches 6 inches or Customized
Description

DTH Button Bit 8 Inches 35° DTH Tools for Mining Quarry for Shank cop84 MS80 BR81 DHD380 QL80 SD8

DTH Hammers And Button Bits

DTH Hammers Are Used For High Air Pressure Mining Dth Hammerblast Hole Drilling And Water Well Drilling Project.

Working With DTH Drilling Pipe And DTH Drill Bit, Mainly Applied In Mining,

Marble Quarry Or Well Drilling And Other Construction Projects.

Diameter No. of Buttons Buttons*Button Diameter (mm) Gauge Buttons Angle° Flushing Hole Weight Approx. Kg Shank
mm Inch Gauge Centre Side Centre 　 　
200 7 7/8 21 8*19 13*19 35° - 2 45.5 cop84
203 8 21 8*19 13*19 35° - 2 47.7
216 8 1/2 20 8*19 12*19 35° - 2 48.6
219 8 5/8 26 10*19 16*19 35° - 2 52.7
222 8 3/4 26 10*19 16*19 35° - 2 61.8
241 9 1/2 27 10*19 17*19 35° - 2 51.8
254 10 30 12*19 18*19 35° - 2 54
305 12 36 10*19 26*19 35° - 2 68.4
200 7 7/8 21 8*19 13*19 35° - 2 45.5 MS80
203 8 21 8*19 13*19 35° - 2 47.7
216 8 1/2 20 8*19 12*19 35° - 2 48.6
219 8 5/8 26 10*19 16*19 35° - 2 52.7
222 8 3/4 26 10*19 16*19 35° - 2 61.8
241 9 1/2 27 10*19 17*19 35° - 2 51.8
254 10 30 12*19 18*19 35° - 2 54
305 12 36 10*19 26*19 35° - 2 68.4
200 7 7/8 21 8*19 13*19 35° - 2 45.5 BR81
203 8 21 8*19 13*19 35° - 2 47.7
216 8 1/2 20 8*19 12*19 35° - 2 48.6
219 8 5/8 26 10*19 16*19 35° - 2 52.7
222 8 3/4 26 10*19 16*19 35° - 2 61.8
241 9 1/2 27 10*19 17*19 35° - 2 51.8
254 10 30 12*19 18*19 35° - 2 54
305 12 36 10*19 26*19 35° - 2 68.4
200 7 7/8 21 8*19 13*19 35° - 2 45.5 DHD380
203 8 21 8*19 13*19 35° - 2 47.7
216 8 1/2 20 8*19 12*19 35° - 2 48.6
219 8 5/8 26 10*19 16*19 35° - 2 52.7
222 8 3/4 26 10*19 16*19 35° - 2 61.8
241 9 1/2 27 10*19 17*19 35° - 2 51.8
254 10 30 12*19 18*19 35° - 2 54
305 12 36 10*19 26*19 35° - 2 68.4
200 7 7/8 21 8*19 13*19 35° - 2 45.5 QL80
203 8 21 8*19 13*19 35° - 2 47.7
216 8 1/2 20 8*19 12*19 35° - 2 48.6
219 8 5/8 26 10*19 16*19 35° - 2 52.7
222 8 3/4 26 10*19 16*19 35° - 2 61.8
241 9 1/2 27 10*19 17*19 35° - 2 51.8
254 10 30 12*19 18*19 35° - 2 54
305 12 36 10*19 26*19 35° - 2 68.4
200 7 7/8 21 8*19 13*19 35° - 2 45.5 SD8
203 8 21 8*19 13*19 35° - 2 47.7
216 8 1/2 20 8*19 12*19 35° - 2 48.6
219 8 5/8 26 10*19 16*19 35° - 2 52.7
222 8 3/4 26 10*19 16*19 35° - 2 61.8
241 9 1/2 27 10*19 17*19 35° - 2 51.8
254 10 30 12*19 18*19 35° - 2 54
305 12 36 10*19 26*19 35° - 2 68.4

High Air Pressure DTH Drilling Tools 8 Inches 35 Degree Down The Hole Hammer BitsHigh Air Pressure DTH Drilling Tools 8 Inches 35 Degree Down The Hole Hammer Bits
