Anti Glare 1080p HD Face Recognition Camera Module Wide Dynamic Range
Anti Glare 1080p HD Face Recognition Camera Module Wide Dynamic Range
Anti Glare 1080p HD Face Recognition Camera Module Wide Dynamic Range
Anti Glare 1080p HD Face Recognition Camera Module Wide Dynamic Range
Anti Glare 1080p HD Face Recognition Camera Module Wide Dynamic Range
Anti Glare 1080p HD Face Recognition Camera Module Wide Dynamic Range
Anti Glare 1080p HD Face Recognition Camera Module Wide Dynamic Range
Anti Glare 1080p HD Face Recognition Camera Module Wide Dynamic Range
Specifications
Brand Name :
Sinoseen
Model Number :
SNS-USB1080P02-V1.0
Certification :
RoHS
Place of Origin :
Shenzhen,China
MOQ :
3
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
500000 pieces/month
Delivery Time :
2-3weeks
Packaging Details :
Tray+Anti-static bag in carton box
Type :
USB camera module
Sensor :
1/2.7" Aptina AR0230
Resolution :
2MP (1920*1080)
Dimensions :
38*38mm (compatible for 32*32)(customizable)
Lens FOV :
90°(optional)
Focus Type :
Fixed focus
Interface :
USB2.0
Feature :
Wide Dynamic Range
Description

Anti Glare 1080p HD Face Recognition Camera Module Wide Dynamic Range

Wide Dynamic Range 1080p HD Anti-Glare WDR USB Camera Module with AR0230 sensor

Face Recognition Camera Module

This is a WDR(wide dynamic range) USB2.0 camera modules with APTINA AR0230 CMOS sensor. It can be used in many applications like face recognition, Automotive, Robotics, Machine vision, ADAS, intelligent machines, kiosk, vending machine, strong/weak light condition, windows/entrance surveillance, etc

Specification

Model No

SNS-USB1080P02-V1.0

Sensor

1/2.7’’ Aptina AR0230

Resolution

2 Mega Pixel

Most effective pixels

1920 X 1080

Pixel Size

3.0μm X 3.0μm

Resolution

See above

Compression format

YUY2/MJPG

Frame rate

See above

Shutter Type

Electronic rolling shutter

Lens FOV

70° and customizable

Input clock frequency

6-48MHz

Focus type

Fixed focus/Manually adjustable

S/N ratio

41dB

Dynamic range

UP to 96dB

Dark current

<10mA

Interface type

USB2.0

Microphone

Optional

Adjustable parameter

Brightness/Contrast/Color saturation/Hue/Definition/
Gamma/White balance/Exposure

Audio frequency

Optional

Power supply

USB BUS POWER

Power consumption

DC 5V, 180mA

Main chip

DSP/SENSOR/FLASH

Automatic Exposure Control (AEC)

Support

Automatic White Balance (AEB)

Support

Automatic Gain Control (AGC)

Support

Dimension

38*38mm (compatible for 32*32)

Storage temperature

-20°C to 70°C

Operating temperature

0°C to 60°C

USB Wire

Default



Support OS

WinXP/Vista/Win7/Win8/Win10
Linux with UVC(above linux-2.6.26)
MAC-OS X 10.4.8 or later
Wince with UVC
Android 4.0 or above with UVC

Anti Glare 1080p HD Face Recognition Camera Module Wide Dynamic RangeAnti Glare 1080p HD Face Recognition Camera Module Wide Dynamic Range

Shenzhen Sinoseen Technology Co.,Ltd

China top 10 camera module manufacturer

We customize all kinds of USB/MIPI/DVP camera module as per your request

Camera Module Application Areas

Imaging and vision solutions Integrated complex and customized technology
Machine vision Intelligent Systems
Future Security Optical technology solutions
Camera Module Customized solutions Internet of Things End-to-End Solution
Iris recognition technology Iris Solutions
Face recognition VR High End Camera Solutions
Smart home solutions Intelligent hardware solutions
Professional camera Modules Specially designed for small UAV
Airborne camera Modules UAV solutions
UAV Special Modules Drone solutions
Aerial filming solutions Optical Technology solutions
Mobile Phone Camera module Camera solutions
Optronics Solutions Imaging Technology Solutions
Video technology solutions Optoelectonic research
Infrared Imagers for Industry Embedded Systems solutions
