Fully Automatic Gas Fired Hot Water Furnace Large Output Environment Protection
Fully Automatic Gas Fired Hot Water Furnace Large Output Environment Protection
Specifications
Brand Name :
Yinyu
Model Number :
CWNS
Certification :
ISO/BV
Place of Origin :
Henan China
MOQ :
1
Price :
$5,000.00-$10,000.00
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100 Qty/per month
Delivery Time :
10-30 work days
Packaging Details :
Loose package
Material :
GB/T 3087-2008
Dimension :
Depends on capacity
Weight :
Depends on capacity
Manufacture :
Yes
Thermal efficiency :
92%-95%
Type :
Nature circulation
Structure :
Fire tube
Style :
Vertical/Horizontal
Output :
Hot water
Warranty :
1 year,Lifetime maintain commitment
Description

Environment Protection Fully Automatic Oil Fired Gas Fired Hot Water Boiler Supply Hot Water

Gas hot water boiler is a kind of hot water boiler, gas hot water boiler gas (such as natural gas, liquefied petroleum gas, urban gas, biogas, etc.) as fuel, through the burner heating of water, to achieve heating and provide life, bath hot water, boiler intelligence is high, heating fast, low noise, no dust, is a very suitable for China's national conditions of the economic hot boiler varieties.

Fully Automatic Gas Fired Hot Water Furnace Large Output Environment Protection

Part of product paremeters

CWNS0.7-95/70

NO; Name Unit Number Description
1 Rated efficiency MW 0.7
2 Water volume M³ 1.4
3 Rated outlet/inlet water temperature ℃ 95/70
4 Heating efficiency % 99
5 Output/inlet diameter mm DN100
6 Design fuels / Oil/Gas
7 Blow down valve diameter mm DN100
8 Heating area(room) ㎡ 6000
9 Hot water output M³/h 18
10 Bulk size mm 2400×1200×1800

CWNS1.4-95/70

NO; Name Unit Number Description
1 Rated efficiency MW 1.4
2 Water volume M³ 3.75
3 Rated outlet/inlet water temperature ℃ 95/70
4 Heating efficiency % 99
5 Output/inlet diameter mm DN125
6 Design fuels / Oil/Gas
7 Blow down valve diameter mm DN125
8 Heating area(room) ㎡ 12500
9 Hot water output M³/h 36
10 Bulk size mm 2800×1700×2300
Our services

Pre-sale service:
We help customer choose the best boiler model according to

different requirements of various industry. Before delivery we

will provide foundation drawing, layout drawing, boiler room

layout, etc.
In-sale service:
We keep 24 hours online and keep close contacts during the

production process to ensure on time delivery with perfect

finished product.
After-sale service:

1. provide full range of original spare parts.
2. Engineers abroad installation and commissioning service is

available.
3. Our engineers will held a training for boiler workers to

ensure the safe operation.
4. Free maintenance and repair for one year and lifelong

service.

Boiler application areas

Fully Automatic Gas Fired Hot Water Furnace Large Output Environment Protection
