Inline Flapper / Dart / Top Entry Check Valve Fig1502 For Oil Gas Drilling
Inline Flapper / Dart / Top Entry Check Valve Fig1502 For Oil Gas Drilling
Inline Flapper / Dart / Top Entry Check Valve Fig1502 For Oil Gas Drilling
Inline Flapper / Dart / Top Entry Check Valve Fig1502 For Oil Gas Drilling
Inline Flapper / Dart / Top Entry Check Valve Fig1502 For Oil Gas Drilling
Inline Flapper / Dart / Top Entry Check Valve Fig1502 For Oil Gas Drilling
Inline Flapper / Dart / Top Entry Check Valve Fig1502 For Oil Gas Drilling
Inline Flapper / Dart / Top Entry Check Valve Fig1502 For Oil Gas Drilling
Specifications
Model Number :
SPM FMC type
Certification :
API 6A
Place of Origin :
China
MOQ :
1 piece
Price :
USD300-800/pc
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
500 pieces per month
Delivery Time :
15-30 work days
Packaging Details :
Export Wooden Case
Product Name :
Inline Flapper Check Valve / Dart Check Valve / Top Entry Check Valve
Keywords :
Flapper Check Valve
Application :
Oil & Gas Drilling
Size :
2", 3", 4"
Working Pressure :
2000 psi ~ 20000 psi
Connection :
Fig1502, 2002
Description

Inline Flapper Check Valve / Dart Check Valve / Top Entry Check Valve

Check valve is a kind of single flow valve to prevent fluid flow back to upstream, which is installed on pipeline. Our check valve is interchangeable with FMC three type check valve which are popular used in oil and gas field. First is dart check valve, second is flapper check valve, third is top entry check vavle. End connection is normally weco hammer union. Sometimes reverse check valve is also adopted.

Flapper Check Valves are designed for well service applications such as fracturing, cementing and acidizing. The flapper check valve is placed in the treating line to allow flow to the well but isolates and back flow to go upstream in the valve. This provides a safety device at various locations in the flow line and assure that pressure and fluid can not backup into the manifold or into pumps.

The check valves provided are available in size ranges in 2", 3" and 4", in pressure ranges from 6,000psi to 20,000psi with hammer union end connections.

Inline Flapper / Dart / Top Entry Check Valve Fig1502 For Oil Gas Drilling

Available Specification

Nomal Size, in Working Pressure, psi End Connection Flow Condition
1 1/2 15,000 Fig1502 M X F H2S
2 15,000 Fig1502 F X M Standard
2 15,000 Fig1502 M X F H2S
2 20,000 Fig2002 F X M Standard
3 6,000 Fig602 F X M Standard
3 6,000 Fig602 M X F H2S
3 6,000 Fig602 F X F Standard
3 15,000 Fig1502 F X M Standard
3 15,000 Fig1502 M X F H2S
3 20,000 Fig2002 F X M Standard
4 6,000 Fig602 F X M Standard
4 10,000 Fig1002 F X M Standard
4 15,000 Fig1502 F X M Standard
4 15,000 Fig1502 M X F H2S

Inline Flapper / Dart / Top Entry Check Valve Fig1502 For Oil Gas Drilling

Any enquiry please contact us by email: christal@oilmancn.com.

Visit our website: www.oilmanchina.com for more products information.

WhatsApp/WeChat:+86 13475294399
