Edible Oil Processing Machine Peanut Seed Oil Expeller Machine
Edible Oil Processing Machine Peanut Seed Oil Expeller Machine
Edible Oil Processing Machine Peanut Seed Oil Expeller Machine
Edible Oil Processing Machine Peanut Seed Oil Expeller Machine
Edible Oil Processing Machine Peanut Seed Oil Expeller Machine
Edible Oil Processing Machine Peanut Seed Oil Expeller Machine
Edible Oil Processing Machine Peanut Seed Oil Expeller Machine
Edible Oil Processing Machine Peanut Seed Oil Expeller Machine
Edible Oil Processing Machine Peanut Seed Oil Expeller Machine
Edible Oil Processing Machine Peanut Seed Oil Expeller Machine
Specifications
Place of Origin :
China
Brand Name :
HP
Certification :
CE 3C
MOQ :
"1 Set/Sets"
Description

Edible Oil Processing Machine Peanut Seed Oil Expeller MachinePRODUCT DESCRIPTION:



YZY260 PRE-PRESS EXPELLER

The machine is suitable for extracting corn germ, rapeseed, cottonseed, peanut, sunflower seeds and other plant oilseeds

Model performance Characteristics:

1.The machine axles, pressing bolt, pressing bar, gear, gear box and other major parts, are all made of high quality steel, then with special processing, high temperature resistant,good wear-resisting performance, high product quality and durable.

2.The barrel screw using light pressure, regular pressure, the pressure step by step and other advanced technology, low residual oil

3.The cake checking mechanism has patented design, easy and quick.

4.Extracting cage has the design of ear plate opening and closing, easy to assembly and maintain, reduce labor intensity.

5.Can be adapted to the high, medium and low temperature pressing.



 Edible Oil Processing Machine Peanut Seed Oil Expeller Machine

YZY260 spiral oil press and 75 kw motor installed base figure

Main technical data:

1.production capacity: pressing 35-45 Ton/Day, prepressing 100-150 ton.

2.Using of steam pressure:3-4kg/cm³.

3.Agitation shaft rotation speed:41 revolutions/Min.

4.Pressing axle rotation speed:28-51 revolutions/Min.

5.Feeding axle rotation speed:85 revolutions/Min.

6.Steaming and frying temperature:60-110ºC.

7.Matching power:75KW.

8.Dimension (Length x Width x Height) :3800×2320×3800mm

9.Net weight:9000kg

Edible Oil Processing Machine Peanut Seed Oil Expeller Machine



Edible Oil Processing Machine Peanut Seed Oil Expeller Machine

Edible Oil Processing Machine Peanut Seed Oil Expeller MachineEdible Oil Processing Machine Peanut Seed Oil Expeller MachineEdible Oil Processing Machine Peanut Seed Oil Expeller MachineEdible Oil Processing Machine Peanut Seed Oil Expeller MachineEdible Oil Processing Machine Peanut Seed Oil Expeller MachineEdible Oil Processing Machine Peanut Seed Oil Expeller MachineEdible Oil Processing Machine Peanut Seed Oil Expeller Machine
