Liquefied Gas Tanker Truck Semi Trailer Capacity 36000L 3 Axles High Effective
Liquefied Gas Tanker Truck Semi Trailer Capacity 36000L 3 Axles High Effective
Liquefied Gas Tanker Truck Semi Trailer Capacity 36000L 3 Axles High Effective
Liquefied Gas Tanker Truck Semi Trailer Capacity 36000L 3 Axles High Effective
Liquefied Gas Tanker Truck Semi Trailer Capacity 36000L 3 Axles High Effective
Liquefied Gas Tanker Truck Semi Trailer Capacity 36000L 3 Axles High Effective
Liquefied Gas Tanker Truck Semi Trailer Capacity 36000L 3 Axles High Effective
Liquefied Gas Tanker Truck Semi Trailer Capacity 36000L 3 Axles High Effective
Specifications
Brand Name :
China Jinggong
Model Number :
HZZ3600GYY
Certification :
ISO9001, CCC
Place of Origin :
Zhejiang.Hangzhou
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
T/T, L/C, Paypal, Western Union
Supply Ability :
10 Units / Months
Delivery Time :
70 days
Packaging Details :
Naked
Tank material :
Tank material:Carbon Steel
Tank Effective Volume :
Tank Effective Volume :36 CBM
Tank Color :
Tank Color: RAL 9016 WHITE SEMI GLOSS MATTE
Description

Oil Tank Trailer / Liquefied Gas Semi-trailer / 3 Axles / Wheel Formula 6x4

The vehicle mainly used for the transportation and storage of hazardous chemical liquid products and oil products shch as gas,diesel. Widely used in transport units, chemical enterprises, gas stations and other industries, this type of vehicle is mainly composed of frame, tank top, unloading system and various protective devices. This type of vehicle is mainly composed of frame, tank, unloading system and various protective devices. The tank color is RAL 9016 WHITE SEMI GLOSS MATTE and the chasis and landing fears is RAL 7043 GREY. It has the characteristics of full structure, reliable performance, beautiful appearance, simple operation and so on.

Competitive Advantage

The tank structure adopts irregular elliptical column. The semi-trailers are mainly manufactured in carbon steel, for easy repair in all the work shop entitled to repair tank and tankers. Relying on intelligent production line for cutting and welding, the semi-trailers get higher quality and higher precision. Furthermore, we minimize the risks of overturns by reducing our gravity center as low as possible. It has the advantages of reasonable structure, reliable performance, beautiful appearance and simple operation.

Specifications

Model HZZ3600GYY
Outer dimension(mm) 11700×2500×3647
Tank Effective Volume (m3) 36
Transporting Medium Gas/Diesel
Tank material Thick carbon steel Q345B
Wheelbase (mm) 5950/1310/1310
Number of Axle 3
Tare weight(Kg) 12300
Payload(Kg) 30240kgs according 0.84 liquid density
Spec. of Tyre 315/80R22.5 PR18/20
Number of spring steel plate 9

Liquefied Gas Tanker Truck Semi Trailer Capacity 36000L 3 Axles High Effective

Liquefied Gas Tanker Truck Semi Trailer Capacity 36000L 3 Axles High Effective

Liquefied Gas Tanker Truck Semi Trailer Capacity 36000L 3 Axles High Effective
