Specifications
Brand Name :
China Jinggong
Model Number :
HZZ5318JQJ22
Certification :
ISO9001, CCC
Place of Origin :
Zhejiang.Hangzhou
MOQ :
No limited
Price :
negotiation
Payment Terms :
T/T, L/C, Paypal, Western Union
Supply Ability :
2Units/Month
Delivery Time :
45days
Packaging Details :
Naked
Port of Delivery: :
Shanghai/Ningbo
MAX LOAD :
MAX LOAD
MAX SPEED :
85KM/H
MAX LOAD OF FRONT END :
250KG
model :
HZZ5318JQJ22
CHASSIS TYPE :
HOWO 8X4
OUTER DIMENSION :
12565X2500X4000
OPERATING RANGE UNDER BRIDGE :
21000mm
Description


High Stability 22m Bridge Inspection Unit rental HOWO 8X4 Electrohydraulic Systems

Quick Details:

Model:HZZ5318JQJ22
Product name:Platform type Bridge Inspection Vehicle
Chassis Model:HOWO Euro 3 RHD
Driver type:8×4
Advantage:low oil consumption, environmental design, ensure high stability.

HOWO Mobile Bridge Inspection Platform Easy Access To Any Position Of Your Bridge

Specifications:

TYPEHZZ5318JQJ22
NAME 22m Platform Bridge Inspection Vehicle
CHASSIS TYPEHOWO EURO 3
TOTAL MASS31000KG
OUTER DIMENSION12565X2500X4000
MAX SPEED85KM/H

SELF-WALK PART

Electro-hydraulic proportional servo system
OPERATING RANGE UNDER BRIDGE(TOTAL) Machanical hydrostatic transmission
OPERATING RANGE UNDER BRIDGE(EFFECTIVE)21000mm
Max crossing sidewalk width3500mm
THE MAX CROSSING SOUND BARRIER HEIGHT4500mm
MAX LOAD600KG
MAX LOAD OF FRONT END250KG
VERTICAL OPERATING RANGE UNDER BRIDGE8500mm
FIRST SCOPE OF ROTATION0~90°
SECOND SCOPE OF ROTATION0~180°
Balancer3.5T,5T Movable balancer, fixed balancer
Operating range for movble balancer950MM
Additional stabler for the rear axleOil cylinder
CONTROL SYSTEMWired/wireless/manual
RESERVE POWERUS kohler generator



Competitive Advantage:

  1. With HOWO EURO 3 Chassis, Has more merits as: low oil consumption, environmental design, ensure high stability.
  2. Air suspension system can adjust the chasis height automaticly, highly increase the stability for such a pot hole ground.
  3. Hydrostatic drive, highly achieved secure in slope and wet road conditions.
  4. Those hydraulic steering wheel system, greatly balance the widthness while operating.
  5. Two sets of control system on platform either into the control box respectively, allows the operator monitor safety.
  6. The hydraulic synchronous interlock device, intercom system, safty lock valve to ensure the safty handing.
  7. US Kohler emergency power supply, able to achieve the folding reset, in case the engine doesn' attent well.
  8. Max. platform payload is 600kg (can affordable 6-7 operators), the tail of the platform payload is about 250kg. The extendable folding platform can be adjustable luffing from 2-4meter, greatly imporve the inspection area under the bridge.
  9. High strength steel platform frame provide more stability which able to rotate 180°under the bridge, and also keep the limitation of max. drop height for 7meter only.
