Stainless Steel Material Chemical Transfer Pump For Water Delivery IH Series
Stainless Steel Material Chemical Transfer Pump For Water Delivery IH Series
Stainless Steel Material Chemical Transfer Pump For Water Delivery IH Series
Stainless Steel Material Chemical Transfer Pump For Water Delivery IH Series
Specifications
Brand Name :
Yuzhou
Model Number :
IH
Certification :
ISO/SGS/CE
Place of Origin :
China
MOQ :
1set
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
500 sets/month
Delivery Time :
3-7 working days
Packaging Details :
Plywood case package
Product Name :
Centrifugal Water Pump
Application :
water
Impeller :
Closed impeller
Structure :
Single stage
Mode :
Horizontal
Warranty :
1 year
Description

IH series stainless steel material chemical transfer pump centrifugal pump for transfer water

IH Series Pump is a single-stage, and single-suction (axial) centrifugal pump with corrosion Resistant-function.Type IH pump is designed by national pump industry according to ISO2858 standard. IH series pump have 40 basic types, among which there are 33 double speed (2900,1450r/min), and can reach 112 specifications after cutting impeller diameter of type A and B.

This kind of pump is energy efficient and has a wide temperature range. It has the advantages of stable operation, low noise and vibration, high reliability and long service life. It is an ideal conveying equipment for alkalis, alcohols and various organic solvents.

2. Usage

It is widely used in chemistry, petroleum, metallurgy, electricity, paper making, food, pharmacy, environmental protection, waste water treatment, synthetic fiber or other industries.

3. Advantage

It's excellent in performance, efficiency and easy in maintenance.

Technical data

Model

Flow

(m3/h)

Lift Head

(m)

Rev

(r/min)

Power

(kw)

 Diameter(mm)
Inlet Outlet
50-32-125 12.5 20 2900 2.2 50 32
6.3 5 1450 0.55
50-32-160 12.5 32 2900 3
6.3 8 1450 0.55
50-32-200 12.5 50 2900 5.5
6.3 12.5 1450 0.75
50-32-250 12.5 80 2900 11
6.3 20 1450 1.5
65-50-125 25 20 2900 3 65 50
12.5 5 1450 0.55
65-50-160 25 32 2900 5.5
12.5 8 1450 0.75
65-40-200 25 50 2900 7.5 65 40
12.5 12.5 1450 1.1
65-40-250 25 80 2900 15
12.5 20 1450 2.2
65-40-315 25 125 2900 30
12.5 32 1450 4
80-65-125 50 20 2900 5.5 80 65
25 5 1450 0.75
80-65-160 50 32 2900 7.5
25 8 1450 1.5
80-50-200 50 50 2900 15 80 50
25 12.5 1450 2.2
80-50-250 50 80 2900 22
25 20 1450 3
80-50-315 50 125 2900 37
25 32 1450 5.5
100-80-125 100 20 2900 11 100 80
50 5 1450 1.5
100-80-160 100 32 2900 15
50 8 1450 2.2
100-65-200 100 50 2900 22 100 65
50 12.5 1450 4
100-65-250 100 80 2900 37
50 20 1450 5.5
100-65-315 100 125 2900 75
50 32 1450 11
125-100-200 200 50 2900 45 125 100
100 12.5 1450 7.5
125-100-250 200 80 2900 75
100 20 1450 11
125-100-315 200 125 2900 110
100 32 1450 15
125-100-400 100 50 1450 30 125 100
150-125-250 200 20 1450 18.5 150 125
150-125-315 200 32 1450 30
150-125-400 200 50 1450 45
200-150-250 400 20 1450 37 200 150
200-150-315 400 32 1450 55
200-150-400 400 50 1450 90

Stainless Steel Material Chemical Transfer Pump For Water Delivery IH Series
