Professional stainless steel 2250RPM - 4000RPM Industrial oil and water Decanter Centrifuge
Professional stainless steel 2250RPM - 4000RPM Industrial oil and water Decanter Centrifuge
Professional stainless steel 2250RPM - 4000RPM Industrial oil and water Decanter Centrifuge
Professional stainless steel 2250RPM - 4000RPM Industrial oil and water Decanter Centrifuge
Professional stainless steel 2250RPM - 4000RPM Industrial oil and water Decanter Centrifuge
Professional stainless steel 2250RPM - 4000RPM Industrial oil and water Decanter Centrifuge
Professional stainless steel 2250RPM - 4000RPM Industrial oil and water Decanter Centrifuge
Professional stainless steel 2250RPM - 4000RPM Industrial oil and water Decanter Centrifuge
Specifications
Place of Origin :
CHINA
Brand Name :
KANGWEI
Certification :
BV
Model Number :
LW250-720
Bowl Diameter :
250-720mm
Bowl Length :
660-1800mm
Max Capacity :
50m3/h
Rated Capacity :
1-55m3/h
Max Bowl Speed :
2250-4000RPM
G-Force :
1820-3639
MOQ :
1set
Price :
negotiated
Packaging Details :
standard container
Delivery Time :
depend on the designing capacity
Payment Terms :
T/T L/C
Supply Ability :
55SETS
Material :
stainless steel SS304/316
motor :
double motor
Description

Professional stainless steel 2250RPM - 4000RPM Industrial oil and water Decanter Centrifuge

Oil and water Decanter Centrifuges

1. For oil & gas well drilling operations are designed with solid bowl diameters of 14 inch to 22 inch and bowl length of 50 inch to 71 inch. Most centrifuges are available in Fixed Speed (G/S marking) and Variable Speed (VFD marking)

2. GN Decanter Cetnrrifuge Features:

2.1. Stainless Steel 316 bowl, conveyor and main body resist corrosion and prolong service life.
2.2. Tungsten alloy tile protects conveyor from wearing and increases solids conveying efficiency.
2.3. Replaceable tungsten carbon allay ring protects solids discharge port.
2.4. German FAG or Sweden SKF Bearings
2.5. Electrical components: SIEMENS/Schneider, ATEX or IEC Ex for option.
2.6. 3 overload safety protection: the first is the safety protection device of the gear box, the second is the hydraulic coupler overload protection, and the third is the control panel with over currency protection.

3.Application:

= chemistry

= pharmacy

= biotechnology

= food and beverage industry

= vegetable oil

= animal fat and regenerative fuels

= waster water

= oil sludg

4.Description:

Bowl Diameter mm/in 450/17.7 450/17.7 355/14 600/23.6
Bowl Length mm/in 842/33.1 1000/39.4 1257/49.5 1000/39.4
Max Capacity m3/h/GPM 40/176 40/176 30/132 60/264
Working Speed(Fixed) RPM 1800/2200 1800/2200 2000/2200/3000 1500
Bowl speed(Fixed) 3300 3600 3900 2600
Bowl Speed(VFD) RPM 0-3300 0-3600 0-3900 0-2600
G-Force 820/1215 820/1215 794/960/2160 755
Separation point µm ≥5 ≥5 ≥3 ≥5
Main Drive Kw/HP 22/30 30/40 22/30/30/40 45/60
Back Drive Kw/HP 5.5/7.5 7.5/10 5.5/7.5/7.5/10 7.5/10

Professional stainless steel 2250RPM - 4000RPM Industrial oil and water Decanter Centrifuge

Professional stainless steel 2250RPM - 4000RPM Industrial oil and water Decanter Centrifuge

Professional stainless steel 2250RPM - 4000RPM Industrial oil and water Decanter Centrifuge
