Din Rail / Wall Mount Industrial Grade Ethernet Switch Single Mode 10Gbps Back Bandwidth
Din Rail / Wall Mount Industrial Grade Ethernet Switch Single Mode 10Gbps Back Bandwidth
Din Rail / Wall Mount Industrial Grade Ethernet Switch Single Mode 10Gbps Back Bandwidth
Din Rail / Wall Mount Industrial Grade Ethernet Switch Single Mode 10Gbps Back Bandwidth
Specifications
Brand Name :
NATYWISH
Model Number :
NTW-SW14GPI
Certification :
CE, ROHS, FCC
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Paypal,Western Union
Supply Ability :
1000/ week
Delivery Time :
7-8 working days
Packaging Details :
1pc/ box
Etherent Port :
4×10/100/1000Base-T
protection :
IP40
Back Bandwidth :
10Gbps
Wavelength :
1310/1550nm
Installation :
Din-Rail mounting, Wall mounting
Fiber Type :
Single mode fiber
Description

Din Rail or Wall Mount Fiber Optic 10/100/1000M 5 Ethernet Port Industrial Switch


Product Description


NTW-SW14GPI is a plug-and-play unmanaged industrial Ethernet switch, which can provide economical solution for your Ethernet. Its dust-proof fully sealed structure(IP40 protection grade), over-current, over-voltage and EMC protected, redundant double power input as well as built-in intelligent alarm design can help system main tenancy personnel monitor the network operation, which can work reliably in harsh and dangerous environment.


NTW-SW14GPI support 5 10/100/1000Base-T(X) Ethernet port. It support CE, FCC, RoHS standard, rugged high-strength metal case, power input (DC10-58V). The switch support IEEE802.3, IEEE802.3u, IEEE802.3x with 10/100/1000Base-T(X), full/half-duplex, and MDI/MDI-X auto-adaptation, the -40-85℃ operating temperature can meet all kinds of industrial environment requirement, providing reliable and economic solution for your industrial Ethernet network.

Main Features:

4 IEEE 802.3af/at PoE compliance 10/100/1000Base-T(X) ports and 1 Up-Link Port . Super lightening protection, IP40 protection Excellent heat elimination without cooling fan. Redundant dual DC power inputs
Input voltage:DC10~58V(Dual power supply redundancy)
Working temperature:-40 ~ + 85°C
Store temperature:-40 ~ + 85°C
Shell: IP40 protection level, DIN-rail, Aluminum profiles, Fanless design
Certifications:FCC/CE/ROHS



Power
IEEE 802.3
IEEE 802.3u
IEEE 802.3l
IEEE 802.3at
Certifications
CE, FCC, RoHS
Etherent Port
4×10/100/1000Base-T auto-adaptive RJ45 connector

Fiber Port
1×100Base-FX(single/multi-mode, single/dual fiber, SC/FC/ST/SFP connector all optional)



Performance
Application-level: Second level
General Back Bandwidth: 10Gbps
Packet Forwarding Rate : 7.44Mpps
MAC: 8K
Buffer Space: 1M
Latency: <4μs
Processing Type: Store and forward
Transmission mode: full-duplex

Power
Input voltage: DC10~58V(Dual power supply redundancy)
Access Terminal: Phoenix terminal
Full-loaded Power: <4W

Transmission Distance
Twisted Pair: 100m (CAT5e, CAT6 cables)
Multi-mode: 2km
Single-mode: 20/40/60/80/100km

LED Indicators
Power: PWR
Connector: Ethernet port and fiber port(Link/ACT)
MTBF
100,000 hours

Environment
Working Temperature: -40 ℃ ~ +85 ℃
Storage Temperature: -40 ℃ ~ +85 ℃
Relative Humidity: 5~95% (no condensation)


Mechanical Structures
Shell: Metal
Cooling method: Natural cooling, without cooling fan
Dimension: 143 x 104 x 48mm
Weight: 0.85KG
Installation: DIN-rail
Warranty
3years

Din Rail / Wall Mount Industrial Grade Ethernet Switch Single Mode 10Gbps Back BandwidthDin Rail / Wall Mount Industrial Grade Ethernet Switch Single Mode 10Gbps Back Bandwidth
