1000M Single Pon Port FTTX ONT High Reliability Point To Multipoint Network Solution
1000M Single Pon Port FTTX ONT High Reliability Point To Multipoint Network Solution
1000M Single Pon Port FTTX ONT High Reliability Point To Multipoint Network Solution
1000M Single Pon Port FTTX ONT High Reliability Point To Multipoint Network Solution
Specifications
Brand Name :
NATYWISH
Model Number :
NTW-E17100H
Certification :
CE, RoHs, FCC
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Paypol
Supply Ability :
5000pcs / day
Delivery Time :
5 - 8 working days
Packaging Details :
1pcs / box, 50 boxes / carton
Support :
IGMP multicast; Route
User nterface :
1GE Port
Size :
105mm(L) ×85mm(W) ×25mm(H)
Weight :
0.2kg
Protocol :
IEEE802.3ah;China Telecom CTC
Power Consumption :
2.5W
Description

1000M single Pon Port 1 GE EPON FTTX ONT point to multipoint network

NTW-E17100H is a new EPON ONU production of Our Company which passive optical network terminal series. It provides one 10/100/1000Mbps base-T interface, one optical interface, and it is very impact. Suitable for home and small business users,it’s good inter-operation with popular EPON OLT in industry by full OAM achievement. With beautiful and practical surface, stable software and strong function, it can meet the requirements of FTTO (Fiber to the Desk), FTTH (Fiber to the Home) etc. applications.

Key Features

  • It takes the PTMP (point to multipoint)network topology, effectively collects and converges scattered Ethernet services, and provides the 10/100/1000M Ethernet standard RJ45 interface, smoothly interconnects with existing networks.
  • The Dynamic Bandwidth Allocation (DBA) mechanism enables all users to share the 1Gbps bandwidth reasonably, guaranteeing a reliable QoS.
  • Supports IGMP multicast, effective use of broadband;
  • Supports multicast VLAN;
  • Supports China Telecom CTC protocol;
  • Full management through an Operation Administration Maintenance (OAM) protocol based on IEEE802.3ah, including configuration, alarm, performance monitoring, fault isolation and security management, etc. It supports remote management through OLT and local console management as well.
  • Supports FEC and DBA;
  • Supports IEEE802.1Q VLAN protocol;
  • Supports IEEE 802.1p protocol;
  • Supports remote loopback and network status diagnosis；
  • Supports flow statistics；
  • Supports storm control;
  • Support NAT;
  • Support PPPOE;
  • Support DHCP Server Client;
  • Support Route;

Technical Parameter

Module NTW-E17100H
User nterface 1 10/100/1000M RJ45 port.
Transmission speed :upstream/downstream symmetrical 1Gbps
Network coverage radius: 20KM
PON Optical receive sensitivity:≥-27dBm
Continuous light power: 0dBm~+4dBm
Security: SFU authentication mechanism
Compliant with IEEE 802.3ah
YD/T 1475-2006
IEEE 802.1D, Spanning Tree
Protocol IEEE 802.1Q, VLAN
IEEE 802.1w, RSTP
IEEE 802.3ad (LACP)
Ethernet–II, Ethernet-SNAP
Support NAT
Route Support PPPOE
Support Server Client
Support Route
Port-based VLAN
VLAN GVRP
IEEE 802.1Q VLAN
Backpressure flow control(half-duplex)
IEEE 802.3x flow control(full-duplex)
QOS Prevent Head Of Line
IEEE 802.1p, CoS
WR,SP and FIFO queue scheduling algorithm
Port rate limit
IEEE 802.1x,access control based upon Port; support local and remote RADIUS.
Safety CHAP,EAP certification;
Storm control, port protection,
Various management modes such as Web, TELNET
Management
Debug function.
Size 105mm(L) ×85mm(W) ×25mm(H)
Operating temperature:0℃～60℃;
Environment Operating humidity:10%～85% non-condensing
Storage temperature:-40℃～80℃;
Storage humidity:5%～95% non-condensing
Power supply 110～240VAC 12V/0.5A DC
power interface size:2.1mm/5.5mm
Power Consumption 2.5W

Order Information

Module Description
NTW-E17100H EPON ONU, One 10/100/1000M RJ45 port. Color: White

Application solution

1000M Single Pon Port FTTX ONT High Reliability Point To Multipoint Network Solution
