17 Port POE Ethernet Switch 14 * 10 / 100M POE Port 3 Uplink Gigabit Ethernet Port
17 Port POE Ethernet Switch 14 * 10 / 100M POE Port 3 Uplink Gigabit Ethernet Port
17 Port POE Ethernet Switch 14 * 10 / 100M POE Port 3 Uplink Gigabit Ethernet Port
17 Port POE Ethernet Switch 14 * 10 / 100M POE Port 3 Uplink Gigabit Ethernet Port
Specifications
Brand Name :
NATYWISH
Model Number :
NTW-PF143G
Certification :
CE, ROHS, FCC
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Paypal,Western Union
Supply Ability :
1000/ week
Delivery Time :
7-8 working days
Packaging Details :
1pc/ box
Connector Type :
14* 10 / 100M POE port and 3*10/100/1000M RJ45 ports
PoE Feature :
All ports support MDI/MDIX
POE Compatibility :
AF/AT self-adaptive
Power input :
AC100-240V 50/60Hz
Package size :
31.8*20.8*4.5cm
Operating Humidity :
max 90%, non-condensing
Description

17 port POE switch ,14 * 10 / 100M POE port , with 3 uplink Gigabit Ethernet port , AF standard

◆ Supports 14* 10 / 100M POE port and 3*10/100/1000M RJ45 ports
◆ Support IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3af / at, store and forward
◆ Compatible with IEEE802.3at (30W) and IEEE802.3af (15.4w)
◆ Ethernet port supports 10 / 100M adaptive and POE functions
◆ With DIP switch support 10M transmission rate via cat.6 transmission distance of up to 250 meters
◆ LED indicators for monitoring power, link, activity and speed

◆ Compatible with 1U Rack-mount chassis Installation

Description

Natywish 17 ports POE Switch, Adapted high-quality high-speed network IC and the most stable POE chip, POE port to meet the 802.3af or 802.3at standard, this series of POE switches can be 10/100M Ethernet Network provides seamless connection, and POE power supply port can automatically detect IEEE802.3af or IEEE802.3at compliant power supply equipment and its power supply,Only transmit data for non-POE equipment .

POE technology (Power over Ethernet) , it refers to some IP-based terminals (such as IP telephones, wireless access AP, network cameras, etc.) while transmitting data signals, but also for the device to provide DC power supply Technology, which receive DC power supply equipment called power receiving equipment.

This series of POE switches, using 14 POE ports + 3 uplink Gigabit Ethernet port, the uplink port is to connect with the network equipment which provide data.

Model No. Description
NTW-PF143G 14-100Base-Tx POE + -10/100/1000Base-Tx, 802.3af

Physical Pic Reference( 14*POE ports + 3 Uplink Gigabit ports)

17 Port POE Ethernet Switch 14 * 10 / 100M POE Port 3 Uplink Gigabit Ethernet Port

Dimension(31.8*20.8*4.5cm, Net Weight: 1.83kg/unit)

17 Port POE Ethernet Switch 14 * 10 / 100M POE Port 3 Uplink Gigabit Ethernet Port

Package Dimension(40.8*27.2*9.3cm,Gross Weight:2kg/unit)

17 Port POE Ethernet Switch 14 * 10 / 100M POE Port 3 Uplink Gigabit Ethernet Port

Order Information


Product: NTW-PF143G
Description: 17-Port 10/100M switch with 14 PoE ports, IEEE 802.3af;

PoE Power Output: 15.4Watts per port.

Accessories in the Package:

17 Port POE Ethernet Switch 14 * 10 / 100M POE Port 3 Uplink Gigabit Ethernet Port

Package Contents 17-Port 10/100M Switch with 14 POE ports and 3 Gigabit Uplink (NTW-PF143G)
DC Adapter( DC52V3.8A, DC52V5.76A Optional)
Rack kit
User Guide
Warranty Card

Technical parameter list
Product Name 14* 10 / 100M POE port and 3*10/100/1000M RJ45 ports
Model NTW-PF143G
Connector Type 14-ports 10/100M POE port, with 3-ports Gigabit Uplink Ethernet port
Optical

Multi mode fiber: 1310nm, 2Km

Single mode fiber: 1310nm, 20/40 Km

1550nm, 60/80/100/120Km
Bandwidth 9.2Gbps (non-blocking)
PoE Standard

IEEE 802.3af( each port 15.4W)

IEEE 802.3at(each port 30W)
POE Compatibility AF/AT self-adaptive
POE power output DC48V
Power Supply Power input: AC100-240V 50/60Hz; (every country use a custom power plug)
PoE power pin 12+,36- ( 45+,78- Optional)
PoE Port Power 15.4W for each POE port
PoE Feature All ports support MDI/MDIX
Network Protocols Support IEEE802.3, IEEE802.3u, IEEE802.3x
MAC address 8K
Network Media

10BASE-T: Cat6 UTP(≤250 meter) ;100BASE-TX: Cat5 or more UTP (≤100 meter);

1000BASE-TX: Cat5 or more UTP (≤100 meter)
LED Indicator

10M: it is on 10Mbps transmission rate while it’s blink

PWR:power is connect while it’s on green

Yellow light; POE Running

Green light: Ethernet Running
Working Environment

Operating Temperature: 0 ° ~ 50° C; Storage Temperature: -40 ° ~ 70 ° C;

Operating Humidity: max 90%, non-condensing
Certification CE,CCC,FCC,RoHs
Transmission Distance

POE transmission distance:100meters, 250meters(when it’s on 10Mbps rate with Cat.6 or more )

Uplink transmission distance: 100meters( Uplink RJ45 port);

Depend on your SFP module( Uplink SFP port)
Warranty 2 year warranty( 1 year warranty for power adapter)
