MZEU30(K) E1+E2 Roller Type One Way Directional Backstop Clutch Bearing
MZEU30(K) E1+E2 Roller Type One Way Directional Backstop Clutch Bearing
MZEU30(K) E1+E2 Roller Type One Way Directional Backstop Clutch Bearing
MZEU30(K) E1+E2 Roller Type One Way Directional Backstop Clutch Bearing
MZEU30(K) E1+E2 Roller Type One Way Directional Backstop Clutch Bearing
MZEU30(K) E1+E2 Roller Type One Way Directional Backstop Clutch Bearing
MZEU30(K) E1+E2 Roller Type One Way Directional Backstop Clutch Bearing
MZEU30(K) E1+E2 Roller Type One Way Directional Backstop Clutch Bearing
MZEU30(K) E1+E2 Roller Type One Way Directional Backstop Clutch Bearing
MZEU30(K) E1+E2 Roller Type One Way Directional Backstop Clutch Bearing
MZEU30(K) E1+E2 Roller Type One Way Directional Backstop Clutch Bearing
MZEU30(K) E1+E2 Roller Type One Way Directional Backstop Clutch Bearing
Specifications
Brand Name :
SUMA
Model Number :
MZEU30(K) E1+E2
Certification :
ISO SGS
Place of Origin :
CHINA
MOQ :
1
Price :
USD150-USD180 PER PIECE
Payment Terms :
L/C, D/A, D/P, T/T, Western Union,Paypal
Supply Ability :
1000PCS Per Month
Delivery Time :
7-15 Days
Packaging Details :
Carton Box / Wooden Box
Product Name :
Roller Clutch Bearing MZEU30(K) E1+E2
Bearing Supported :
YES
Material :
Bearing Steel GCr15
Size :
30*100*68mm
Torque capacity :
735Nm
Warranty :
1 Year
Package :
Carton Box / Wooden Box
Weight :
4Kg
Description

MZEU30(K) E1+E2 Roller Type One Way Directional Backstop Clutch Bearing

Installation and Usage
1. Model No’s. MZEU12 to MZEU80 are pre-greased and require no lubrication. The operational temperature range is –40°C to +40°C. Model No’s. MZEU90 to MZEU150 require oil lubrication. (Refer to lubrication and maintenance on page 31).
2. We recommend a Shaft tolerance of h7, and ISO R773 (DIN 6885.1) keyway is standard.
3. We recommend tolerances of B H7 or H8 for sprockets, gears and other fitted parts.
4. The clutch is delivered with a Basic type Cam Clutch, E1 flange and E2 flange as separate parts.
5. Clean the surface of both ends of the outer race and the contact surfaces of the flanges.
6. For Model No’s. MZEU90 to MZEU150, apply seal adhesive to the surface of the outer race at both ends.
7. Check the direction of rotation and attach the E1 and E2 flanges to clutch.

Dimensions and Capacities

Model Torque
Capacity
Max. Overrunning		 Drag
Torque		 Bore Size Keyway A B BF C DF F M N Weight

Inner

Race

Outer

Race
Nm r/min r/min Nm H7 Inner Race h7 kg
MZEU12(K)E1+E2 60 2,000 1,000 0.20 12 4X 1.8 42 62 85 20 72 20 10.0 5.7 1.1
MZEU15(K)E1+E2 100 1,800 900 0.20 15 5 X 2.3 52 68 92 28 78 25 11.0 5.7 1.5
MZEU20(K)E1+E2 245 1,600 700 0.29 20 6X 2.8 57 75 98 34 85 30 10.5 5.7 1.9
MZEU25(K)E1+E2 425 1,600 600 0.33 25 8X 3.3 60 90 118 35 104 40 11.5 6.8 2.9
MZEU30(K)E1+E2 735 1,500 500 0.39 30 8X3.3 68 100 128 43 114 45 11.5 6.8 4.0
MZEU35(K)E1+E2 1,015 1,400 300 0.49 35 10X3.3 74 110 140 45 124 50 13.5 6.8 5.2
MZEU40(K)E1+E2 1,350 1,400 300 0.59 40 12X3.3 86 125 160 53 142 55 15.5 9.0 7.9
MZEU45(K)E1+E2 1,620 1,400 300 0.69 45 14X3.8 86 130 165 53 146 60 15.5 9.0 9.3
MZEU50(K)E1+E2 2,070 1,300 250 0.79 50 14X3.8 94 150 185 64 166 70 14.0 9.0 11.7
MZEU55(K)E1+E2 2,400 1,300 250 0.88 55 16X4.3 104 160 204 66 182 75 18.0 11.0 15.3
MZEU60(K)E1+E2 2,950 1,200 250 0.98 60 18X4.4 114 170 214 78 192 80 17.0 11.0 17.7
MZEU70(K)E1+E2 4,210 1,100 250 1.27 70 20X4.9 134 190 234 95 212 90 18.5 11.0 25.5
MZEU80(K)E1+E2 5,170 800 200 1.38 80 22X5.4 144 210 254 100 232 105 21.0 11.0 33.2
MZEU90(K)E1+E2 12,000 450 150 4.70 90 25X5.4 158 230 278 115 254 120 20.5 13.0 38.3
MZEU100(K)E1+E2 17,600 400 130 5.39 100 28X 6.4 182 270 335 120 305 140 30.0 17.5 68.8
MZEU130(K)E1+E2 24,500 320 110 6.76 130 32X7.4 212 310 380 152 345 160 29.0 17.5 98.2
MZEU150(K)E1+E2 33,800 240 80 8.13 150 36X8.4 246 400 485 180 445 200 32.0 21.5 198.2

MZEU30(K) E1+E2 Roller Type One Way Directional Backstop Clutch Bearing

Mounting and Coupling

MZEU30(K) E1+E2 Roller Type One Way Directional Backstop Clutch Bearing


8. When installing sprockets, gears and other equipment to the clutch, fit them on the surface of the outer race and screw the bolts into the E1 flange.
9. By installing both the flange and sprocket on the opposite side, the direction of rotation can be changed.
10. When mounting the clutch onto the shaft, apply pressure to inner race but never to the outer race.
11. For high speed Indexing applications (More than 50 c/m) a strong spring type is recommended.
12. Model No.
This drawing shows MZEU E1+E2
MZEU K
No Mark : No keyway on the outer race.
K : Keyway on the outer race.
