Roller Type GN110 One Way Freewheel Backstop Bearing Clutch
Roller Type GN110 One Way Freewheel Backstop Bearing Clutch
Roller Type GN110 One Way Freewheel Backstop Bearing Clutch
Roller Type GN110 One Way Freewheel Backstop Bearing Clutch
Roller Type GN110 One Way Freewheel Backstop Bearing Clutch
Roller Type GN110 One Way Freewheel Backstop Bearing Clutch
Roller Type GN110 One Way Freewheel Backstop Bearing Clutch
Roller Type GN110 One Way Freewheel Backstop Bearing Clutch
Roller Type GN110 One Way Freewheel Backstop Bearing Clutch
Roller Type GN110 One Way Freewheel Backstop Bearing Clutch
Specifications
Brand Name :
SUMA
Model Number :
GN90/GN100/GN110
Certification :
ISO SGS
Place of Origin :
CHINA
MOQ :
1 PC
Price :
USD260-USD320 PER PIECE
Payment Terms :
L/C, D/A, D/P, T/T, Western Union,Paypal
Supply Ability :
2000 PCS PER MONTH
Delivery Time :
7-15 Days
Packaging Details :
Wooden Box
Product Name :
Backstop Clutch
Material :
Bearing Steel GCr15
Structure :
Roller Type / Sprag Type
Bore Diameter :
90/100/110mm
Application :
Reducer / Gearbox
Port :
ShangHai / NingBo
Weight :
95Kg
Installation Size :
90*400mm
Description

GN90 GN100 GN110 One-Way Bearing Freewheel Backstop Clutch

Feature

GN series backstop clutch is a kind of low speed of roller type plugging device,often with reducer,used in

belt conveyor,hoist,electric drum, and other need a non-return device.

Non-return quickly ,small reverse distance,long life , can withstand the torque
Dimension and Capacity

Roller Type GN110 One Way Freewheel Backstop Bearing Clutch

Type Torque Bore Dia. Max. Size Weight Recommended Suitable Reducer
TKN ødH7 bxt C L B C1 B1 H H1 D1 kg
N.m mm mm mm mm mm mm mm mm mm mm
GN110 6770 110 32X6.7 400 450 140 90 140 160 310 ø21 89.4 ZQ650
ZQ750
GN130 13700 130 36X7.4 430 480 170 120 180 175 340 120 ZQ850
GN140 13700 140 36X7.4 430 480 170 120 190 175 340 105 ZQ85
GN150 22800 150 40X8.7 510 580 190 170 230 215 420 ø26 186 ZQ1000
GN170 22800 170 40X8.7 510 580 190 170 250 215 420 182 ZL100
GN200 47600 200 45X9.9 590 660 220 210 290 275 540 ø32 352 ZL115
GN220 47600 220 50X11.2 590 660 220 210 290 275 540 339 ZL130


Roller Type GN110 One Way Freewheel Backstop Bearing Clutch

Roller Type GN110 One Way Freewheel Backstop Bearing Clutch
