Specifications
Brand Name :
HKING
Model Number :
EG8143A5
Certification :
CE,ISO,RoHS
Place of Origin :
China
MOQ :
100pcs
Price :
USD30-32/pcs
Payment Terms :
T/T
Supply Ability :
100000/week
Delivery Time :
5-8days
Packaging Details :
Packed with Polyfoam, Outer Packed with Brown Box
COLOR :
WHITE
Usage :
FTTH
Firmware :
English
Condition :
New
PON :
XPON
Description

Product Description

Original Huawei CATV EG8143A5 EPON XGPON Gpon onu 1GE+3FE 1TEL with English version
Product Description

Model Configuration Dimension/pcs
LAN Telephone Wifi PPPOE Firmware
CATV EG8143A5 1GE+3FE 1pots yes yes English 250*185*35mm/0.44kgs
Remarks External Antenna
Features:
1 .Full compatible with ITU-T G.984.
2.Support port-based rate limitation and bandwidth control
3.Integrated OMCI remote configuration and maintenance function.
4.Support data enscryption, group broadcasting, port Vlan separation ,RSTP,etc.
5.Support Dynamic Bandwidth Allocation (DBA)
6.Support ONT auto-discovery/Link detection/remote upgrade of software;
7.Support VLAN division and user separation to avoid broadcast storm;
8.Support power-off alarm function ,easy for link problem detection
9.Support broadcasting storm resistance function
10.Support port isolation between different ports
11.Support ACL and SNMP to configure data packet filter flexibly
12.Specialized design for system breakdown prevention to maintain stable system
13.Support software online upgrading
14.EMS network management based on SNMP ,convenient for maintenance
Hardware Specifications
PON Interface
Interface Type
SC/PC, CLASS B+
Rate
Uplink: 1.25Gbps; Downlink: 2.5Gbps
User-Side Interface
1*10/100/1000BASE-T;1*10/100BASE-T;1*RF interface
Size (Mm)
167(L)×118(W)×30(H)
Maximum Power Consumption
<8W
Weight
120g
Operating Environment
Temperature: -10°C ~ 55°C
Humidity: 5% ~ 95% (no condensation)
Power Supply
External Power Adapter 12V/1A
Power Adapter Input
100-240V AC, 50/60Hz
Power Interface Size
metal inner diameter: φ2.1±0.1mmouter diameter : φ5.5±0.1mm; length: 9.0±0.1mm
WLAN Module
External dual antenna, antenna gain 5db, antenna power 16~21dbm
Support 2.4GHz, 300M transmission rate
