Outdoor 6/8/12 Core Single Mode Fiber Optic Cable Rodent Proof Direct Buried
Outdoor 6/8/12 Core Single Mode Fiber Optic Cable Rodent Proof Direct Buried
Outdoor 6/8/12 Core Single Mode Fiber Optic Cable Rodent Proof Direct Buried
Outdoor 6/8/12 Core Single Mode Fiber Optic Cable Rodent Proof Direct Buried
Specifications
Brand Name :
Yiyuan
Certification :
OHSAS 18001, ISO 14001, ISO 9001
Place of Origin :
China
MOQ :
1KM
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
500000km/month
Delivery Time :
30 working days after received your payment
Packaging Details :
Wood coil strand
Product Name :
Flame Retardant Cable
Number of Cores :
4-12 core
Outer Sheath Material :
PVC PE
Application :
Outdoor duct/outdoor cable/aerial/lashed
Color :
Black or customized
Number of Conductors :
≥ 10
Package :
Wood coil strand
Fiber Type :
Single mode
Strength member :
steel wire
Description

Outdoor 6/8/12 Core Single Mode Fiber Optic Cable Rodent Proof Direct Buried

Product Description


Single-mode/multimode fibers are positioned in the loose tubes, the tubes are filled with water blocking filling compound.Tubes and fillers are stranded around the strength member into a circular cable core. Then the cable is completed with a PE sheath. Which is filled with the filling compound to protect it. After PSP is applied over the inner sheath, the cable is completed with a PE outer sheath.

Items Specifications
Fiber Count 12
Colored Coating Fiber Dimension 250µm±15µm
Color

Blue,Orange,Green,Brown,Gray,White,Red,Black,Yellow,Purple,
Pink,Aqua
Loose Tube Dimension 2.5mm±0.05mm
Material PBT
Color Natural
Strength Member Diameter 1.0mm
Material Steel Wire
PSP Diameter 4.1 mm±0.1mm
Thickness 0.45mm
Outer Jacket Dimension 9.0mm±0.3mm
Material HDPE
Color Black

Cable Type

(Increased by 2 fibers)

 Fiber Count

Tubes

+ Fillers

 Fiber in Tube

Cable Diameter

mm

Cable Weight

kg/km

Tensile Strength

Long/Short Term N

Crush Resistance

Long/Short Term N/100mm
GYTY53 2 ~36 2 ~36 6 6 12.6 184 1000/3000 1000/3000
GYTY53 38 ~ 72 38 ~ 72 6 12 14.0 216 1000/3000 1000/3000
GYTY53 74 ~ 96 74 ~ 96 8 12 15.7 260 1000/3000 1000/3000
GYTY53 98 ~ 120 98 ~ 120 10 12 17.4 301 1000/3000 1000/3000
GYTY53 122 ~ 144 122 ~ 144 12 12 19.0 354 1000/3000 1000/3000
GYTY53 144 ~ 288 144 ~ 288 18 12 19.0 350 1000/3000 1000/3000


Features

  1. Excellent mechanical and temperature performance.
  2. Loose tube gel-filled construction for superior fiber protection.
  3. 100% core filling water prevent cable jelly to ensure the cable watertight.
  4. Crush resistance and flexibility.
  5. Outer sheath UV protection and waterproof design.

FAQ
1. Are you trading company or manufacturer?
We are the manufacturer with 12 years experience.
2. About the quality?
After price confirmation, you can require for samples to check our quality.
3. Can you accept small order?
Yes, small order is available. We support new project of our customers, as we know business is always from small order.
4. What is your delivery time?
It mainly depend on order quantity.But pls be assured that we will arrange your goods asap after your payment .
5. Can you accept the OEM service?
Yes, we welcome the OEM service. We can print your logo on the product. Any idea from you is available.
