Duct Aerial Armored 48 Pair Fiber Optic Cable Aluminum Tape Metallic Strength Member
Duct Aerial Armored 48 Pair Fiber Optic Cable Aluminum Tape Metallic Strength Member
Specifications
Brand Name :
Yiyuan
Certification :
ISO 9001;ISO 14001;OHSAS 18001
Place of Origin :
China
MOQ :
1KM
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
500000km/month
Delivery Time :
30 working days after received your payment
Packaging Details :
Wood coil strand
Product Name :
Non Metallic Fiber Optic Cable
Number of Cores :
2-144 core
Outer Sheath Material :
PE
OEM :
Accepted
Application :
Outdoor duct/outdoor cable/aerial/lashed
Color :
Black or customized
Number of Conductors :
≥ 10
Installation :
Self-supporting Aerial
Package :
Plywood Reel/customized
Fiber Type :
Single mode
Strength member :
FRP
Description

Duct Aerial Armored 48 Pair Fiber Optic Cable Aluminum Tape Metallic Strength Member

Quick Description

GYTA is one of our outdoor fiber optic cable with aluminum armored sheath and metallic strength member inside. Its a type of fiber optic cable in stranded loose tube with compact structure and the cable jacket is made of strong polyethylene.

High strength loose tube has hydrolysis resistant. Cable filling materials ensure high reliability, and APL makes the cable crush resistant and moisture proof. So, the GYTA has a very good watertight performance. This cable can be used for LAN and WAN backbones, telecom access lines, fibre to business and fibre to the building drop connections, as well as fibre to the home drop and access connections.

Features

1. Good mechanical and temperature performance.

2. High strength loose tube that is hydrolysis resistant.

3. Special tube filling compound ensure a critical protection of fiber.

4. Crush resistance and flexibility.

5. Small diameter, light weight and friendly installation.

Application

  1. CATV

  2. Local trunk line

  3. Rural communication

  4. Computer networks system

  5. Aerial & conduit/duct application

Optical Characteristics

G.652 G.655 50/125 µm 62.5/125 µm
Attenuation(+20℃) @ 850 nm ≤ 3.0 dB/km ≤ 3.0 dB/km
@1300 nm ≤ 1.0 dB/km ≤ 1.0 dB/km
@1310 nm ≤ 0.36 dB/km ≤ 0.40 dB/km
@1550 nm ≤ 0.22 dB/km ≤ 0.23 dB/km
Bandwidth(Class A) @ 850 nm ≥ 500 MHz·km ≥ 200 MHz·km
@1300 nm ≥ 1000 MHz·km ≥ 600 MHz·km
Numerical Aperture 0.200 ± 0.015 NA 0.275 ± 0.015 NA
Cable Cut-off Wavelength lcc ≤ 1260 nm ≤ 1450 nm
