Specifications
Brand Name :
Yiyuan
Certification :
ISO 9001;ISO 14001;OHSAS 18001
Place of Origin :
China
MOQ :
1KM
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
500000km/month
Delivery Time :
30 working days after received your payment
Packaging Details :
Wood coil strand
Product Name :
Non Metallic Fiber Optic Cable
Number of Cores :
2-144 core
Outer Sheath Material :
PE
OEM :
Accepted
Application :
Outdoor duct/outdoor cable/aerial/lashed
Color :
Black or customized
Number of Conductors :
≥ 10
Installation :
Self-supporting Aerial
Package :
Plywood Reel/customized
Fiber Type :
Single mode
Strength member :
FRP
Description

12 Strand Non Metallic Fiber Optic Cable Rodent Proof Fiber Double Sheath

Description

The fibers, 250µm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. A steel wire, sometimes sheathed with polyethylene (PE) for cable with high fiber count, locates in the center of core as a metallic strength member. Tubes (and fillers) are stranded around the strength member into a compact and circular cable core. An Aluminum Polyethylene Laminate (APL) is applied around the cable core, which is filled with the filling compound to protect it from water ingress. Then the cable core is covered with a thin PE inner sheath. After the PSP is longitudinally applied over the inner sheath, the cable is completed with a PE outer sheath.

Features

- Good mechanical and temperature performance

- High strength loose tube that is hydrolysis resistant

- Special tube filling compound ensure a critical protection of fiber

- Crush resistance and flexibility

- The following measures are taken to ensure the cable watertight

- Steel wire used as the central strength member

- Loose tube filling compound

- 100% cable core filling

- APL moisture barrier

- PSP enhancing moisture-proof

- Water-blocking material

Technical data

Fiber Num. Outer diameter (mm) Weight (kg/km) Tension (N) Crash loading (N/100mm)
Short term Long term Short term Long term
2-30 12.9 160 3000 1000 3000 1000
32-60 13.4 175
62-72 14.1 204
74-84 15.4 245
86-96 15.4 245
98-120 17.2 285
122-144 19 334

Perormance

Application : Used for long haul communication and local network

Installation method : burial and duct

Operating temperature : -40°C ~ +70°C

Permisson bent radius Static :12.5 times O.D.

Dynamic :25 times O.D.
