2×2B Optical Network Switch Mechanical Compact Size Low Insertion Loss
2×2B Optical Network Switch Mechanical Compact Size Low Insertion Loss
Specifications
Brand Name :
SPACECOM or OEM
Model Number :
2*2B-D-5L-SM-025-15-00
Certification :
CE RoHS FCC
Place of Origin :
China
MOQ :
1pcs
Price :
Get latest price
Payment Terms :
T/T, WU, PayPal, Moneygram, L/C, Western Union
Supply Ability :
1000pcs/month
Delivery Time :
3-7 working days
Packaging Details :
Carton packing
Warranty :
1Years
Application :
FTTH FTTB FTTX Network
name :
2×2B Mechanical Optical Switch
Keyword :
Fiber Optical Switch
Operating Voltage :
3.0 V or 5.0V
Operating Temperature :
-5~70ºC
Dimension :
L27×W12×H8.2 (±0.2)
Description

2×2B Mechanical Optical Switch

Features

  • Fast Switching Time
  • Compact Size
  • Low Insertion Loss
  • High Reliability and stability

Specification

  • PON Network
  • Protection
  • Network Monitoring
  • ​Instrumentation

Compliance

  • Telcordia GR-1221
  • Telcordia GR-1073
Specifications
Parameters Unit FSW 2×2B
Working Wavelength nm 1260~1620 for SM, 850/1310 for MM

Insertion Loss

dB

≤0.8 (A Grade)

≤0.6 (P Grade)
WDL dB ≤0.25
TDL dB ≤0.2
PDL dB ≤0.05
Return Loss dB SM≥50, MM≥30
Crosstalk dB SM≥55, MM≥35
Repeatability dB ≤±0.02
Switching Time ms ≤8
Durability times ≥107
Operating Voltage V 3.0 or 5.0
Input Optical Power mW ≤500
Operating Temp. °C -5 ~ +70
Storage Temp. °C -40 ~ +85
Operating humidity % 5 ~ 95
Dimension mm L27×W12×H8.2 (±0.2)

1. Within operating temperature and all SOP.

2.Excluding connector.


Pin Configuration

Type

State

Optical Route

Pin1

Electric Drive

Pin5 Pin6

Pin10

Pin2-3

Status Sensor

Pin3-4 Pin7-8

Pin8-9

Latching

Non- Latching

 A P1-P4 - - GND V+ Close Open Open Close
B P1-P3 P2-P4 V+ GND - - Open Close Close Open
A P1-P2 - - - - Close Open Open Close
B P1-P3 P2-P4 V+ - - GND Open Close Close Open

Quality control


2×2B Optical Network Switch Mechanical Compact Size Low Insertion Loss

2×2B Optical Network Switch Mechanical Compact Size Low Insertion Loss

More Question

1. Can I have a sample order?What is your MOQ?

Yes, we welcome sample order to test and check quality. We do not have MOQ,1 sample is available.


2. What is the lead time?
For usual products,We keep stock,could ship about 3 days after received payment.For big quantity and special products,Please check lead time with our sales representative.


3. How do you ship the goods and how long does it take arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive.


4. What is your payment terms?
Usually,we need prepayment by T/T,West Union or Paypal.

Could also support L/C,Credit terms.

5. What is your warranty time
We promise 3 years warranty for all products shipped from us.


6. Could I return the products if there is a quality problem?
Yes,if there is a quality problem happen,we could accept free exchange.

7. Could i use our own logo and label?

Yes,we could provide a OEM service and make the products with your own label.
