Multimode Cisco Sfp Module 850nm Compliant 40Gb/S QSFP+ 850nm 150m Optical Transceiver
Multimode Cisco Sfp Module 850nm Compliant 40Gb/S QSFP+ 850nm 150m Optical Transceiver
Specifications
Brand Name :
SPACECOM or OEM
Model Number :
SPC-QSFP-40G-SR4
Certification :
CE RoHS FCC
Place of Origin :
China
MOQ :
1pcs
Price :
Get latest price
Payment Terms :
T/T, WU, PayPal, Moneygram, L/C, Western Union
Supply Ability :
35,000pcs per week
Delivery Time :
3-7 working days
Packaging Details :
10 or 20 pcs/ plastic tray or individual
Wavelength :
850nm
Distance :
150m (MM)
Fiber type :
dualfiber
Warranty :
3 Years
Application :
FTTH FTTB FTTX Network
name :
40G QSFP SR4 150m MPO Optical Transceiver
keyword :
850nm Optical Transceiver Module
Description

Compliant 40Gb/s QSFP+ 850nm 150m Optical Transceiver for Cisco

Description


SPACECOM QSFP 40G SR4 are designed for use in 40 Gigabit per second links over multimode fiber.They are compliant

with the QSFP+ MSA and IEEE 802.3ba 40GBASE-SR4.

The optical transmitter portion of the transceiver incorporates a 4-channel VCSEL (Vertical Cavity Surface Emitting Laser)
array, a 4-channel input buffer and laser driver, diagnostic monitors, control and bias blocks. For module control,
the control interface incorporates a Two Wire Serial interface of clock and data signals.

Product Name: 40G QSFP SR4 150m 850nm Model Name: QSFP-40G-SR4
Wavelength: 850nm Data Rate: 40Gbps
Transmission Distance: 150m Connector Type: MPO
DDM: YES Working Environment: Commercial 0~70℃
Cable Type: MMF Compatibility: Multiple brands of switches

Features

  • High Channel Capacity: 40 Gbps per module
  • Up to 11.1Gbps Data rate per channel
  • Maximum link length of 100m links on OM3 multimode fiber
    Or 150m links on OM4 multimode fiber
  • High Reliability 850nm VCSEL technology
  • Electrically hot-pluggable
  • Digital diagnostic SFF-8436 compliant
  • Case operating temperature range:0°C to 70°C
  • Power dissipation < 0.7 W

Applications

  • 40G Ethernet
  • Infiniband QDR
  • Fiber channel

Standards

  • Compliant to IEEE 802.3ba
  • Compliant to SFF-8436
  • RoHS Compliant.

Quality control


Multimode Cisco Sfp Module 850nm Compliant 40Gb/S QSFP+ 850nm 150m Optical Transceiver

Multimode Cisco Sfp Module 850nm Compliant 40Gb/S QSFP+ 850nm 150m Optical Transceiver

More Question

1. Can I have a sample order?What is your MOQ?

Yes, we welcome sample order to test and check quality. We do not have MOQ,1 sample is available.


2. What is the lead time?
For usual products,We keep stock,could ship about 3 days after received payment.For big quantity and special products,Please check lead time with our sales representative.


3. How do you ship the goods and how long does it take arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive.


4. What is your payment terms?
Usually,we need prepayment by T/T,West Union or Paypal.

Could also support L/C,Credit terms.

5. What is your warranty time
We promise 3 years warranty for all products shipped from us.


6. Could I return the products if there is a quality problem?
Yes,if there is a quality problem happen,we could accept free exchange.

7. Could i use our own logo and label?

Yes,we could provide a OEM service and make the products with your own label.

Multimode Cisco Sfp Module 850nm Compliant 40Gb/S QSFP+ 850nm 150m Optical Transceiver
