LSZH Gpon Epon G657A2 1x64 PLC Fiber Optic Splitter
LSZH Gpon Epon G657A2 1x64 PLC Fiber Optic Splitter
LSZH Gpon Epon G657A2 1x64 PLC Fiber Optic Splitter
LSZH Gpon Epon G657A2 1x64 PLC Fiber Optic Splitter
LSZH Gpon Epon G657A2 1x64 PLC Fiber Optic Splitter
LSZH Gpon Epon G657A2 1x64 PLC Fiber Optic Splitter
LSZH Gpon Epon G657A2 1x64 PLC Fiber Optic Splitter
LSZH Gpon Epon G657A2 1x64 PLC Fiber Optic Splitter
Specifications
Brand Name :
SUNWISE
Model Number :
PLCS1224
Certification :
CE/TUV/ISO9001
Place of Origin :
CHINA
Application :
FTTH FTTB FTTX Network,Telecom/network
Color :
blue,blue or as required,aqua,Yellow,Green
Fiber type :
G657A2
Connector type :
SC; FC; LC; ST; MTRJ; MU; E2000; MPO; SMA; FDDI; DIN4; D4
Insertion loss :
< 0.2dB,≤0.1dB
Length :
Any length is customizable
Wavelength :
1310nm/1550nm/850nm/1300nm
Material :
LSZH,PVC
Connector :
SC/LC/FC/ST
Type :
PC/UPC/APC,Om3 Fiber optic patch cord
Fiber mode :
single mode & multi mode
Description

1x2 1x4 1x8 1x16 1x32 1x64 Gpon Epon PLC fiber optic splitter

APPLICATION

FTTx Systems
Digital, hybrid and AM-Video systems
LAN,WAN and Metro Networks
CATV systems
Other applications in fiber optic systems

FEATURES

Low Insertion loss and Low PDL
Uniform power splitting
High reliability
Excellent environmental stability
Compact size and various package

LSZH Gpon Epon G657A2 1x64 PLC Fiber Optic Splitter

LSZH Gpon Epon G657A2 1x64 PLC Fiber Optic Splitter

LSZH Gpon Epon G657A2 1x64 PLC Fiber Optic Splitter

Parameter/Type
Nx2(N=1or2)
Nx4(N=1or2)
Nx8(N=1or2)
Nx16(N=1or2)
Nx32(N=1or2)
Nx64(N=1or2)
Fiber
9/125 um SMF-28e or customer appoint
Operating Wavelength(nm)
1260~1650(nm)
Insertion Loss
≤3.9dB
≤7.1dB
≤10.3dB
≤13.3dB
≤16.3dB
≤19.8dB
Loss Uniformity(dB)
≤0.6dB
≤0.6dB
≤0.8dB
≤1.2dB
≤1.5dB
≤2.0dB
Polariation Dependent Loss
≤0.15dB
≤0.15dB
≤0.2dB
≤0.2dB
≤0.2dB
≤0.3dB
Return Loss
UPC≥50dB APC≥60dB
Directivity
≥55dB
Working Temperature(℃)
-40°C to +85°C
Product tags

1x64 plc fiber optical splitter

,

optical fiber 1x4 plc splitter

,

fiber optic 1x32 plc splitter
