10g Ethernet Sfp Copper Module Data Center Transceiver Dual Fiber Single Fiber
10g Ethernet Sfp Copper Module Data Center Transceiver Dual Fiber Single Fiber
Specifications
Brand Name :
sunwise
Model Number :
GPON ONU STICK
Certification :
ROHS CE
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
Western union,T/T,PayPal
Supply Ability :
1 million km / month for fiber optic cables; 200,000 pcs / month for patch cords;100,000 PCS / month for equipment
Delivery Time :
jumper 3 ~ 7 days; fiber optic cable and equipment 7 ~ 15 days
Packaging Details :
jumper 63 * 63 * 45 ; carton equipment / optical cable,carton + wooden optical cable shaft
Product name :
10g SFP ER 40km,fiber transceiver
Fiber type :
SMF,Dual fiber Single fiber
Application :
FTTH FTTB FTTX Network
Connector type :
SC
Data rate :
1G~11.7Gbps
Speed :
2.5G
Description

10g Ethernet Sfp Copper Module Data Center Transceiver Dual Fiber Single Fiber

Features

  • Support ITU-T G.984 GPON Networks application
  • Support ITU-T G.988 ONU management and control interface (OMCI) specification
  • Support Dying Gasp function (optional)
  • Configurable 1G or 2.5G UNI, MAC inside
  • Single fiber bi-directional data links with asymmetric 1.244Gbps Tx and 2.488Gbps Rx
  • 1310nm burst-mode transmitter with DFB laser
  • 1490nm continuous-mode receiver with APD-TIA
  • 2-wire interface for integrated digital diagnostic Monitoring
  • SFP package with SC/UPC or SC/APC receptacle optical interface
  • Single +3.3V power supply
  • Operation case temperature -40~85°C for industrial and 0~70°C for commercial
  • RoHS6 compliance

Applications

10GBASE-ER/EW Ethernet

Sonet OC-192/SDH

10G Fibre channel

DWDM Networks

PON TO PON

Part Number Product Description
PON OLT Tx1490nm, Rx1310nm , 2.5Gbps/1.25Gbps, Class B+, 0ºC ~ +70ºC With Digital Diagnostic Monitoring

Part Number Product Description
PON ONU Rx1490nm, Tx1310nm , 2.5Gbps/1.25Gbps, Class B+, 0ºC ~ +70ºC With Digital Diagnostic Monitoring

EPON OLT PX20+ EPON OLT PX20+, 20km, Tx 1490nm 1.25G, Rx 1310nm 1.25G, SFP form-factor, SC/UPC receptacle connector, Commercial temperature
EPON OLT PX20++ EPON OLT PX20++, 20km, Tx 1490nm 1.25G, Rx 1310nm 1.25G, SFP form-factor, SC/UPC recetacle connector, Commercial temperature TX5 ~7db
EPON OLT 7dBm EPON OLT PX20++ Enhanced, 20km, Tx 1490nm 1.25G, Rx 1310nm 1.25G, SFP form-factor, SC/UPC receptacle connector, Commercial temperature 7DB
GPON OLT B+ GPON OLT B+, 20km, TX 1490nm 2.488Gbps, RX 1310nm 1.244Gbps, SFP, BIDI SC/UPC Receptacle, Commercial Temperature
GPON OLT C+ GPON OLT C+, 20km, TX 1490nm 2.488Gbps, RX 1310nm 1.244Gbps, SFP, BIDI SC/UPC Receptacle, Commercial Temperature
GPON OLT C++ GPON OLT C++, 20km, TX 1490nm 2.488Gbps, RX 1310nm 1.244Gbps, SFP, BIDI SC/UPC Receptacle, Commercial Temperature
GPON OLT 7dBm GPON OLT C++ Enhanced, 20km, TX 1490nm 2.488Gbps, RX 1310nm 1.244Gbps, SFP+, BIDI SC/UPC Receptacle, Commercial Temperature
GPON ONU SFP GPON ONU SFP, G.984.5, 20km, Tx 1310nm 1.244G, Rx 1490nm 2.488G, SFP form-factor, SC/UPC receptacle connector, Industrial temperature, BEN low active
EPON ONU SFP EPON ONU SFP, G.984.2, 20km, Tx 1310nm 1.25G, Rx 1490nm 1.25G, SFP form-factor, SC/UPC receptacle connector, Commercial temperature
GPON ONU STICKER B+ SFP ONU SFP MAC/ Tx1310/Rx1490 DFB+APD 1.25G/2.5G

What is your quality control for your fiber optic product ?

1. Source Guarantee. We have our own long-term cooperation raw material suppliers. All the products are ROHS certificated and satisfy exporting quality level demand.
2. Quality Test. It runs through the whole process from the raw material to finished product, such as package, surface, physical test, optical test. They are 100% tested.
3. Optical Test. Our products are strictly tested in accordance with IEC and ITU standard.
4. We have 30% spot test by Quality Assurance Department after the products finished.
