Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame
Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame
Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame
Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame
Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame
Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame
Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame
Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame
Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame
Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame
Specifications
Brand Name :
sunwise
Model Number :
ODF-01
Place of Origin :
CHINA
MOQ :
Negotiable
Supply Ability :
1 million km / month for fiber optic cables; 200,000 pcs / month for patch cords;100,000 PCS / month for equipment
Product name :
fiber optic adapter
Type :
Single mode/ Multi-mode,PC/UPC/APC
Insertion loss :
≤ 0.2dB(SM&MM)
Application :
FTTH FTTB FTTX Network,indoor/outdoor,Telecommunication/Fiber Optic CATV/Multimedia
Certification :
ISO9001,RoHS,CE,ROSH N Type Attenuator,Telecom
Storage temperature :
-40℃~+75℃
Price :
Negotiable
Packaging Details :
jumper 63 * 63 * 45 ; carton equipment / optical cable,carton + wooden optical cable shaft
Delivery Time :
jumper 3 ~ 7 days; fiber optic cable and equipment 7 ~ 15 days
Payment Terms :
Western union,T/T,PayPal
Description

Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame

Types of ODF:

According to the structure, ODF can mainly be divided into three types, namely wall mount ODF, floor mount ODF and rack mount ODF.

Rack mount ODF:

(shown in the right picture) is usually modularity in design with firm structure. It can be installed on the rack with more flexibility according to the fiber optic cable counts and specifications. This kind of optical distribution system is more convenient and can provide more possibilities to the future variations. Most of the rack mount ODF is 19”, which ensures that they can be perfectly installed on to the commonly used standard transmission rack.

Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame

Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame

Wall mount ODF:

(shown in the right picture) usually uses design like a small box which can be installed on the wall and is suitable for fiber distribution with small counts. Floor mount ODF adopts closed structure. It is usually designed with relatively fixed fiber capacity and nice appearance.

Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame

Rack Mount ODF Unit Introduction:

ODF is mainly used for cable inlet, grounding and fixing and the splicing between the terminal end and pigtail. Users can select unit or ring flange amount according to their practical needs.
19" ODF offers flexible cabling access, expandable frame design and comprehensive management. A series of optical distribution frames of 12 fibers, 24 fibers, 48 fibers, 72 fibers,96 fibers and 144 fibers counts type are available.ODFwith pigtails and adapters contain one ODF, adapters and pigtails.

Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame

Mount ODF Unit Application:
1) Telecommunications subscriber loop
2) Fiber to the home (FTTH)
3) LAN/WAN
4) CATV

Rack Mount ODF Unit Features:
1) Standard size, light weight and reasonable structure
2) Splice tray inside changeable
3) Can be used in 19'', 23'' standard distribution frame
4) Suitable for ribbon and single fiber
5) Various panel plate to fit different adapter interface
6) Front mark on the plate is easy for identification and operation
7) 24C, 36C, 48C, 72C optional, with or without fiber optic pigtails and adapters
8) Easy for management and operation

Technical Information:
Type: Cable installation, wall mount
Size: 40x38x14cm , 30x30x8.5cm, 40.5x38.2x8.5cm
Capacity: 48 SC, 96 LC
Connector options: SC, SC/APC, LC, LC/APC, ST, FC

Operating/Storage Temperature: -20 to +80°C

Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame

Model

Core Count

Height

Dimension(cm)

Weight(kg)

ODF-R144

144

7U

49x30.5x31.15

17.1

ODF-R96

96

5U

49x30.5x22.25

11

ODF-R72

72

4U

49x30.5x17.8

9

ODF-R48

48

3U

49x30.5x13.35

7

ODF-R36

36

2U

49x30.5x8.9

5.7

ODF-R24

24

2U

49x30.5x8.9

4.6

Lc Sc Apc FTTH Fiber Optic ODF 144 96 72 48 Port Core Cable Odf Distribution Frame

Model

Fiber Quantity

Dimension(cm)

Weight(Kg)

ODF-IW48

48

40x38x14

5.8

ODF-IW24

24

40.5x38.2x8.5

4.2

ODF-IW12B

12

30x30x8.5

3
