3m Optical Fiber Patch Cable
3m Optical Fiber Patch Cable
Specifications
Brand Name :
SUNWISE
Model Number :
DIN
Certification :
ROHS
Place of Origin :
CHINA
MOQ :
Negotiation
Price :
Negotiated
Application :
FTTH FTTB FTTX Network,LAN
Fiber type :
G657A2,G652D,Singlemode or multimode,SM/MM/OM3
Connector type :
SC; FC; LC; ST; MTRJ; MU; E2000; MPO; SMA; FDDI; DIN4; D4
Product name :
Armored Fiber Optic Patch Cable Cord
Insertion loss :
≤0.2 dB
Description

DIN-DIN SM SX 3m fiber optic patch cord high performance fiber jumper

Fiber optic patch cord optical fiber patch cord

Our optical fiber patch cord is high return loss and low insertion loss ,Insertion loss of fiber patch cord is less than 0.2dB,Return loss of fiber patch cord is UPC more than 55dB ,APC is more than 60dB

Standard: IEC, Telcordia GR-326-CORE

Operating temperature range: -40°C--80°C

Polish:PC/UPC

Storage temperature range: -40°C--80°C

Patch cord Tensile strength: >10kg

Fiber patch cord diameter: 0.9mm, 2.0mm, 3.0mm fiber is available

Fiber jacket PVC or LSZH cable is available

Fiber optic patch cord with excellent changeability and repeatability

Applications

1. CATV

2. Active dvice termination

3. Telecommunication networks

4. Metro

5. Local Area Networks(LANs)

6. Data Processing networks

7. Test Equipment

8. Premise installations.

9. Wide Area Networks(WANs)

3m Optical Fiber Patch Cable

Spec. fiber optic patch cord
Insertion loss Less than 0.2dB
Return loss MM more than 35dB
SM more than 55dB
Repeatability Less than 0.2dB
Changeability Less than 0.1dB
Operting termperature -40°C~80°C
Storage temperature -40°C~80°C
Tensile strength >10kg
Min.bending radius 35mm
Length Customized

Ordering Information

Boot Connector Fiber Type Cable number Ferrule Length Color

0.9mm

2.0mm

3.0mm

FC

LC

SC

ST

MU

D4

MTRJ

MPO

DIN

E2000

9/125um SM

50/125um MM

62.5/125um MM

OM3

OM4

Simplex

Duplex

PC

UPC

1m

2m

3m

4m

5m

......

Customized

Aqua

Black

Biege

Blue

Gray

Orange

White

Yellow

3m Optical Fiber Patch Cable
