Xfp Zr 120km Lc Xfp Fiber Connector For Ftth And Sdh , Xfp Single Mode
Xfp Zr 120km Lc Xfp Fiber Connector For Ftth And Sdh , Xfp Single Mode
Specifications
Brand Name :
Sourcelight or OEM
Model Number :
XFP 120KM ZR
Certification :
CE/FCC/RoHS/TUV/UL
Place of Origin :
Shenzhen,China
MOQ :
1PCS
Price :
Get Latest Price
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100PCS Per Week
Delivery Time :
Shipped in 1~3 days after PO confirmed
Packaging Details :
10PCS or 20PCS Plastic trays; 1pc gift Box.
Datarate :
10Gbps
Wavelength :
1550NM
Distance :
120KM (with EDFA)
Receiver :
APD
RX Sensitivity :
-24dBm
Connector :
Duplex LC/UPC
Description

Xfp Zr 120km 1550nm Lc Optical Transceiver Module For Ftth And Sdh

Overview
Sourcelight 120km XFP Transceiver can be used to compensate channel impairments caused by either single mode fiber up to 120 km with EDFA .All modules satisfy class I laser safety requirements. sourcelight XFP transceiver provides an enhanced monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.


Features

  • XFP MSA Rev 4.5 Compliant
  • Data rate from 9.95Gbps to 11.095Gbps
  • Reference Clock Options
  • Cooled 1550 nm EML and APD receiver
  • link length up to 120km (with EDFA)
  • 2400ps/nm Dispersion Tolerance for 120km Single mode fiber
  • +1.8V,+3.3V,+5V Supply Voltage
  • Low Power Dissipation 3.5W Maximum
  • XFI and lineside loopback Mode Supported


Parameter

P/N 10G-XFP-ZR 120KM
Datarate 10G/ps
Distance 120KM
Wavelength 1550nm
Transmitter EML
Receiver APD
Media SMF
DDM/DOM YES
Connector LC
Application Ethernet/SONET/10G FC
Operating Temperature 0℃~ +70℃
Voltage Supply 3.3V/5V
Certification CE/FCC/RoHS/TUV/UL
Brand Neuter, OEM

Application

  • SONET OC-192&SDH STM 64 (with/with out FEC)
  • 10GBASE ER/EW (with/with out FEC)
  • 10G Fiber Channel

Xfp Zr 120km Lc Xfp Fiber Connector For Ftth And Sdh , Xfp Single Mode
10G XFP

10G-XFP-SR 10G-XFP-SR-SL 10GBASE-SR 850nm MMF 300m
10G-XFP-LR 10G-XFP-LR-SL 10GBASE-LR 1310nm SMF 10km
10G-XFP-ER40 10G-XFP-ER-SL 10GBASE-ER 1550nm SMF 40km
10G-XFP-ZR80 10G-XFP-ZR-SL 10GBASE-ZR 1550nm SMF 80km
